Control Panel - Electrum CGH611LX Mode D'emploi

6.

CONTROL PANEL

 Press " " button, and the motor will stop.
 Press " " button and the motor runs at low speed.
 Press " " button and the motor runs at middle speed.
 Press " " button and the motor runs at high speed.
 Press " " button and lights will be on. Press it again
and the light will be off.
7. CHANGE LAMPS
Use the screw driver loosen the ST4*8MM self tapping screws from the lighting
panel, take out the lighting fixtur e. Open the terminal box that connected with
the wire, disconnect the wire connector and replace the lamp.
Note：Light replacement should carried out by qualified service personnel only.
• ILCOS D code for this lamp is: DBS-2/65-H-120/33
– LED modules –rectangle lamp
– Max wattage: 2 W
– Voltage range: AC 110-240V
CAUTION: Do not touch bulbs with your bare hands.
8. Cleaning
- Unplug the appliance from the mains and let it cool down before commencing any
cleaning.
- To prevent causing a fire hazard, it is necessary to clean the filters at least
every 2 months, as follows: Remove the filters from the extractor hood and clean them
with water and neutral detergent, leaving the dirt to soften. Rinse with plenty of
lukewarm water and leave to dry.
First remove the grille by pulling down on it. Undo the side
catches.
You can now clean the anti-grease filter grilles.
Soak them for about one hour in hot water with a grease-loosening
detergent then rinse off thoroughly with hot water.
- Clean the appliance with a damp cloth impregnated with a few
drops or detergent and dries it afterwards.
- Do not use solvents or products with an acidic ph value to clean the appliance, or
bleach or abrasive products.
- Do not submerge the appliance in water or any other liquid or place it under a
running tap.
- Repeat the process if needed.
- Re-fit the grease grilles when dry.
