This may have the following causes:
• Passage points, where connection cables are passed
through windows or doors.
• Kinks where the connection cable has been improp-
erly fastened or routed.
• Places where the connection cables have been cut
due to being driven over.
• Insulation damage due to being ripped out of the wall
outlet.
• Cracks due to the insulation ageing.
Such damaged electrical connection cables must not
be used and are life-threatening due to the insulation
damage.
Check the electrical connection cables for damage reg-
ularly. Make sure that the connection cable does not
hang on the power network during the inspection.
Electrical connection cables must comply with the ap-
plicable VDE and DIN provisions. Only use connection
cables with the marking „H 07 RN".
The printing of the type designation on the connection
cable is mandatory.
AC motor
• The mains voltage must be 230 V~
• Extension cables up to 25 m long must have a cross-
section of 1.5 mm .
2
Connections and repairs of electrical equipment may
only be carried out by an electrician.
Please provide the following information in the event
of any enquiries:
• Type of current for the motor
• Machine data - type plate
• Machine data - type plate

Accessories

SAW DUST EXTRACTION
The mitre saw is equipped with an extraction port to
which an extraction system can be connected. Alterna-
tively, a dust bag can also be attached.
The hose of the extraction system is fastened on the
extraction port with a clamp. We recommend emptying
the bag or container from time to time and cleaning the
filter.
The air speed of the suction system must be at least 30
metres per second.
m Maintenance
Pull out the mains plug before carrying out any ad-
justments, maintenance or servicing work.
If personnel qualified for unusual maintenance
tasks or repairs must be obtained during of after
the warranty period, please always contact a ser-
vice point recommended by us or contact the man-
ufacturer.
• Only perform repair, maintenance and cleaning work
as well as the correction of malfunctions with the
drive switched off as a basic rule.
26 GB
• All protective and safety equipment must be reas-
sembled immediately after repair, maintenance is
completed.
NORMAL SERVICE TASKS
Normal service tasks can also be performed by un-
trained personnel and are all described in the preceding
sections and in this chapter.
• The mitre saw must not be lubricated, because it al-
ways cuts dry surfaces; all moving machine parts are
self-lubricating.
• In the event of service work, personal protective
equipment must always be work (protective goggles
and gloves).
• Remove saw dust and chips regularly by cleaning the
cutting zone and support surfaces.
We recommend using a suction tool or brush.
ATTENTION: Do not use compressed air!
Check the saw blade from time to time: If problems
arise with the blade, it must be ground by a specialist
or replaced, depending on the condition.
DECOMMISSIONING OF THE MACHINE
After the machine is decommissioned it can be dis-
posed of with normal industrial waste.
Service information
Please note that the following parts of this product are
subject to normal or natural wear and that the following
parts are therefore also required for use as consuma-
bles.
Wear parts*: carbon brushes, saw blade, batteries, table
insert, Dust bag, fan belt
* Not necessarily included in the scope of delivery!

Disposal and recycling

The equipment is supplied in packaging to prevent it
from being damaged in transit. The raw materials in
this packaging can be reused or recycled. Never place
batteries in your household refuse, in fire or in water.
Batteries should be collected, recycled or disposed of
by environment-friendly means. The equipment and its
accessories are made of various types of material, such
as metal and plastic. Defective components must be
disposed of as special waste. Ask your dealer or your
local council.
Old devices must not be disposed of with house-
hold waste!
This symbol indicates that this product must not
be disposed of together with domestic waste in
compliance with the Directive (2012/19/EU) per-
taining to waste electrical and electronic equip-
ment (WEEE). This product must be disposed of at a
designated collection point. This can occur, for exam-
ple, by handing it in at an authorised collecting point for
the recycling of waste electrical and electronic equip-
ment.
