JVC KD-R528 Manuel D'instructions page 14

Menu item
DAY COLOR
NIGHT COLOR BUTTON ZONE
MENU COLOR ON : Changes the display and buttons (except for DISP / BRIGHTNESS / 0)
DIMMER SET
BRIGHTNESS
SCROLL *
TAG DISPLAY ON : Shows the Tag information while playing MP3/WMA tracks. / OFF : Cancels.
PRO EQ
FADER *
BALANCE *
LOUD
VOL ADJUST
L/O MODE *
SUB.W
* 2 For KD-R528.
* 3
The illumination control lead connection is required. (See "Installation/Connection Manual.") This setting may not work
correctly on some vehicles (particularly on those having a control dial for dimming). In this case, change the setting to
any other than <DIMMER AUTO>.
* 4
Some characters or symbols will not be shown correctly (or will be blanked) on the display.
* 5
If you are using a two-speaker system, set the fader level to "00."
6
* This adjustment will not affect the subwoofer output.
* 7
For KD-R528/KD-R520/KD-R428/KD-R420.
14 ENGLISH
BUTTON ZONE You can create your own day and night colors for <BUTTON ZONE>
DISP ZONE
DISP ZONE
illumination during menu, list search and playback mode operations. / OFF : Cancels.
AUTO : Changes the display and button illumination between the Day/Night
adjustments in <BRIGHTNESS>/<COLOR SETUP *
on the car headlights. *
<COLOR SETUP * 2
Day adjustments in <BRIGHTNESS>/ <COLOR SETUP *
button illumination.
DAY [ 31 ] / NIGHT [ 15 ] : Selects the display and button illumination brightness
level [00 — 31] for day and night.
4 ONCE : Scrolls the displayed information once. / AUTO : Repeats scrolling (at 5-second
intervals). / OFF : Cancels.
(Pressing DISP for more than one second can scroll the display regardless of the setting.)
For settings, see page 13.
5, * 6 R06 — F06 [ 00 ] : Adjusts the front and rear speaker output balance.
6 L06 — R06 [ 00 ] : Adjusts the left and right speaker output balance.
ON : Boost low and high frequencies to produce a well-balanced sound at a low volume
level. / OFF : Cancels.
–05 — +05 [ 00 ] : Presets the volume adjustment level of each source (except
"FM"), compared to the FM volume level. The volume level will automatically increase or
decrease when you change the source. Before adjustment, select the source you want to
adjust. ("VOL ADJ FIX" appears on the display if "FM" is selected as the source.)
7 SUB.W : Selects if the REAR/SW terminals are used for connecting a subwoofer (through
an external amplifier). / REAR : Selects if the REAR/SW terminals are used for connecting
the speakers (through an external amplifier).
(For KD-A525) ON : Turns on the subwoofer output. / OFF : Cancels.
Selectable setting, [Initial: Underlined]
and <DISP ZONE> separately.
Perform step 2 to select a primary color (RED/ GREEN/ BLUE),
then adjust the level [00 — 31]. Repeat this procedure until you
have adjusted all the three primary colors.
• If "00" is selected for all the primary colors for <DISP ZONE>,
nothing appear on the display.
3
/ ON : Selects the Night adjustments in <BRIGHTNESS>/
> setting for the display and button illumination. / OFF : Selects the
2
> setting when you turn off/
2
> setting for the display and
