General Guidelines - HQ Power RLL45B Mode D'emploi

Rope lights - Lichtslang - Lumineux - Mangueras luminosas - Lichtschlange

Use the original packaging if the device is to be transported.
3.

General Guidelines

Refer to the Velleman® Service and Quality Warranty on the last pages of this manual.
4. Features
All rope lights and led rope lights:

come with 2 power cables (RLOPC), 2 inline connectors (RLIC), and 2 end caps (RLEC)

can be cut each 100 cm
5. Overview
Refer to the illustrations on page 2 of this manual.
Part
1 Power cord
2 Power connector
3 Rope light
4 End cap
6. Initial test
Always refer to the safety instructions above.
Before installing or using the rope light, test the rope light and keep it plugged in to warm up the plastic.
This makes it more pliable when installing.
7. Assembling rope lights
Switch off the mains power before you continue.
Connecting the power connector
1. Slide the heatshrink over the ropelight.
2. Firmly push the sharp prongs of the power connector into the
rope light. Make sure the prongs are pushed in all the way and
make contact with the tube light leads.
3. Push the power connector firmly into the connector sleeve.
4. Use a heat gun to shrink the heatshrink over the connector.
V. 06 – 06/02/2013
Description
Connects the power cord to the rope light
Inner wires run the length of the rope light; can be cut at certain intervals
(cut marks are indicated on sheath
Protects the exposed ends of the rope light.

)
3 ©Velleman nv
