Introduction; Technical Data - Ksenia ergo A KSI2100030.301 WHITE Manuel D'installation

INTRODUCTION

A is the outdoor soft-touch keypad in Bluetooth Tecnology ideal for access control
ergo
A senses an authorized compatible bluetooth device ( mobile phone )
application. As soon as
ergo
within its detection range, enables access without the need to get your mobile out of your
pocket. Moreover, you can open a door using a numerical code.
EN

TECHNICAL DATA

• Soft-Touch Technology
• Available colors: White, Grey, Black
• Up to 18 codes and 6 Bluetooth compatible mobile phones can be programmed
• 1 relay output (max. 60VDC or 24VAC, 500mA, 10Watt)
• Encrypted communication between keypad and relay module
• Degree of protection: IP54
• Supply voltage: 9-24 VDC or 9-12 VAC
• Consumption: 250 mA max
• Operating temperature: -20°C ÷ +60°C
• Front panel dimensions: 48 x 93,5 x 3 mm
• Housing dimensions; 45,5 x 91,5 x 18,5 mm
• Weight: 48 g
9
