Specifications - AKG Acoustics PERCEPTION 150 Mode D'emploi

Type:
Polar pattern:
Frequency range:
Sensitivity:
Max. SPL for 0.5% THD:
Equivalent noise level
to CCIR 468-2:
Equivalent noise level
to IEC 60268-4:
Signal/noise ratio
(A-weighted):
Preattenuation pad:
Impedance:
Recommended load impedance: ≥ 1000 ohms
Supply voltage:
Current consumption:
PERCEPTION 150
0.5-inch diaphragm, externally
polarized condenser microphone
cardioid
20 Hz to 20 kHz
(see frequency response graph)
12 mV/Pa (-38.5 dBV ±3 dB)
135 / 145 dB SPL (0 / -10 dB)
< 32 dB
< 21 dB-A
73 dB (re 1 Pa)
-10 dB (switchable)
≤ 200 ohms
48 V ±4 V phantom power
to DIN 45 596 / IEC 268-15
≤ 2 mA
Environment:
Connector:
Dimensions:
Net weight:
F F C C C C S S t t a a t t e e m m e e n n t t
The device complies with part 15 of the FCC rules. Operation is
subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, includ-
ing interference that may cause undesired operation.

7 Specifications

temperature: -14°F to 140°F
humidity: 80% (@ 77°F)
3-pin XLR (pin 2 hot)
22 dia. x 160 mm high
(0.9 x 6.3 in.)
130 g / 0.29 lbs.
9
