8 Technical data

General
Dimensions 80 x 60 x 40 (l x w x h) in mm
Power supply Via OpenTherm Smart Power or separate 5 Vdc adapter (300mA)
Digital input Potential-free contact (switch)
RF 868.3 MHz, bi-directional secure communication
Ambient conditions
Temperature: -25°C–60°C
Storage conditions
Relative humidity: 5% - 90%, no condensation
Operating conditions 0°C–60°C.
The range of the iSense RF in buildings is generally 30 metres. The
Wireless range range is influenced strongly by the prevailing situation (see paragraph
3.1)
Quality marks and compliance with standards
EMC: 2004/108/EC – EN50165(1997), 55014, 55022
Emission EN61000-6-3
Immunity EN61000-6-2
Drop test: IEC 68-2-32
RoHS compliant
OpenTherm V3.0
ETSI 300-220
Protection class IP20
tabel 04 Technical specification
EN
33
