 Delayed alarms
The 3 alarms are activated: visual (backlight on), sound (buzzer on), and Relay
The delay of alarm is programmable through the configuration menu from 0 to 90 minutes
HT
TEMPERATURE
Backlight color
ACTIONS
Conclusions:
The Alarm delay is identified by a violet backlight color (no sound, no relay). After an acknowledgement,
the backlight turns to green less than 1 second if the temperature is still above the high threshold.
It is the same for the low threshold.
c) Inhibit
The 3 alarms are activated: visual (backlight on), sound (buzzer on) and Relay
HT
TEMPERATURE
Backlight color
ACTIONS
Conclusions:
Inhibit stops all the activated alarms. Activation must be done to restore normal settings and remove
alarm inhibitions.
It is the same for the low threshold.

3) Technical alarm

The 3 alarms are activated: visual (backlight on), sound (buzzer on) and Relay
Technical alarms are:
NO_SENSOR_CH1
NO_SENSOR_CH2
BATTERY_ALARM
FULL_MEM_ALARM
Alarm management for no sensor on ch1 or 2, full memory, no gauging and memory failure alarms:
©JRI Maxant
Below
alarm delay
S+R S+R

Inhibit

S+R
Above
alarm delay
Activate
PARAM_TAB_DEFAULT
NO_GAUGING
MEMORY_FAILURE
S+R
Acknowledgement
