Conclusions :
The buzzer stops after pressing
again.
It is the same for the low threshold.
 Delayed alarm
The 3 alarms are activated: visual (backlight on), sound (buzzer on), and Relay
The delay of alarm is programmable through the configuration menu from 0 to 90 minutes
.
HT
TEMPERATURE
Backlight color
ACTIONS
Conclusions:
The Alarm delay is identified by a violet backlight color (no sound, no relay). After an acknowledgement,
the backlight turns to green less than 1 second if the temperature is still above the high threshold..
It is the same for the low threshold.
b) Acknowledgement
 Threshold overstep
The 3 alarms are activated : visual (backlight on), sound (buzzer on), and Relay
HT
TEMPERATURE
Backlight color
ACTIONS
Conclusions:
After the acknowledgement, the recorder comes back to normal but only if the problem has been
corrected and the temperature has returned below the high threshold.
It is the same for the low threshold.
©JRI Maxant
, but turns on again if the temperature oversteps the threshold
Below alarm
delay
S+R S+R

Acknowledgement

S+R
Above
Alarm Delay
S+R
S+R
Acknowledgement
S+R
Stop
buzzer
