RYMASKON 200 - Modbus
RYMASKON ® stands for a series of multifunctional room control units. The individually configurable RYMASKON
automated monitoring and control of the indoor climate and illumination in a Modbus network. It provides three digital inputs and a universal input,
which allows connection of up to four external push buttons or switches. It can be configured remotely from a higher-level Modbus master and
integrated into a cross-building room climate monitoring and data acquisition system. Internal sensors record room temperature, relative humidity
and dew point.
Up to eight capacitive function buttons on the front panel of the compact unit can be used for on-site operation and configuration. A buzzer sounds
to acknowledge button use and can also be used as an acoustic fault or alarm warning. The dimmable multifunctional display is designed specifically
for room operation and uses intuitive symbols for a clear view of all available spatial data. Besides the time, date and climate para meters (temperature,
humidity, dew point, CO content), it can also display additional features, such as fan mode or room occupancy. The back light colour can be adapted
2
to the room design.

TECHNICAL DATA

Power supply:
Power consumption:
Inputs:
Bus interface:
Equipment:
Operating elements:
TEMPERATURE
Sensor:
Measuring Range:
Accuracy:
HUMIDIT Y
Sensor:
Measuring Range:
Accuracy:
Electrical connection:
Housing:
Dimensions:
Mounting:
Ambient temperature:
Permitted humidity:
Protection type:
Standards:
CONTROL
RYMASKON 210:
RYMASKON 220:
RYMASKON 230:
RYMASKON 240:
RYMASKON 250:
RYMASKON 260:
24 V DC (± 10 %)
max. 0.8 W
3 digital inputs (for standard push buttons or switches)
1 universal input (can be configured for connecting NTC10K temperature sensors or
as additional digital input for the connection of standard push buttons or switches)
RS485 Modbus RTU slave (57600, 38400, 19200, 9600 Baud),
bus termination can be set via DIP switch,
configurable speed 1200-115200 bit/s (typically 57600 bit/s),
adjustable transfer mode (typically "8E1", 1 start bit, 8 data bits, even parity, 1 stop bit)
1 NFC (Near Field Communication)
1 infra-red receiver (NEC protocol)
1 buzzer
1 backlit multifunctional display (individually programmable RGB colour selection)
4 / 6 / 8 touch buttons, type-dependent
CMOS temperature sensor
–40...+125 °C, resolution: 0.1 °C
typically ±0.5 °C (at +5...+60 °C)
capacitative humidity sensor
0...100 % r.H., resolution: 0.1 % r.H.
typically ±2 % r.H. (at +25 °C, 20...80 % r.H.)
typically ±3 % r.H. (at +25 °C, 0...20 % r.H. or 80...100 % r.H.)
0.2 - 1.5 mm², via plug-in screw terminals
plastic, black or white colour
approx. 94.5 x 110 x 19.5 mm
using a plastic mounting plate (see dimensional drawing), on in-wall flush box, Ø 55 mm
0...+50 °C (operation)
0...90 % r. H. (without dew formation)
IP 30 (according to EN 60 529)
CE conformity, electromagnetic compatibility according to EN 50491, EMC directive 2014 ⁄ 30 ⁄ EU
Temperature up/down, Room occupancy, Menu
Temperature up/down, Fan speed up/down, Room occupancy, Menu
Temperature up/down, Fan speed up/down, Light on/off, Room occupancy, Menu
Temperature up/down, Sun protection up/down, Light on/off, Room occupancy, Menu
Temperature up/down, Fan speed up/down, Sun protection up/down, Room occupancy, Menu
Temperature up/down, Fan speed up/down, Sun protection up/down, Light, Menu
Rev. 2021 - V14
® 200 - Modbus enables
