Height Adjustment; Seat Tilt Position Adjustment; Tilting Compensation Adjustment; Backrest Height Adjustment (If Present) - tecnodent StingST Mode D'emploi

4.2. H
EIGHT ADJUSTMENT
In order to adjust the stool seat height in a comfortable way, it is recommended to sit on the stool and use your own body weight.
By pushing the lever L downwards, the stool moves downwards under body weight.
By pushing the lever L downwards while standing up to eliminate body weight pressure on the stool, the stool moves
upwards.
4.3. S
EAT TILT POSITION ADJUSTMENT
To adjust the seat tilt position (and, if present, of the backrest) in the most comfortable way, it's recommended to sit on the stool
and use your own body weight. Then, follow these instructions:
Unlock the lever L, by pushing it backwards;
Use body weight to push and unlock the mechanism;
Move the backbone to find the desired position;
Lock lever L, by pushing it forward;
Settle on the seat to make it hook to the nearest pre-defined position
By keeping unlocked the lever, the stool is free to tilt, and follows the operator's weight balance.
4.4. T
ILTING COMPENSATION ADJUSTMENT
The stool is provided with a mechanism which, allows to vary the compensation force of the operator's weight, when the tilting
command is unlocked.
Rotate the knob B clockwise to increase weight compensation strength.
Rotate it anti-clockwise to obtain the opposite effect.
4.5. B
ACKREST HEIGHT ADJUSTMENT
It is recommended to adjust the backrest position from the rear of the stool:
Unscrew the knob P;
Set the desired backrest height;
Tighten back the knob P.
4.6. F
OOTREST RING HEIGHT ADJUSTMENT
To adjust the stool's footrest ring height, follow these instructions:
Unscrew the knob M;
Set the desired footrest ring height;
Tighten the knob M.
StingST and StingLE stools are made to require no maintenance during their life. There are thus no specific re-adjustments to
be carried out at any time.
If the stool is not used for some time, it is recommended to cover it in order to protect it against dust.
WARNING.
It is recommended to have any technical adjustment as well as any repair of the stool carried out by
specialized maintenance technicians.
5.1. C .
LEANING
For a better and longer life of the stool it must be cleaned methodically and periodically.
Proceed as follows.
CAUTION.
It is recommended to avoid the use of any solvent, detergent or strong abrasive agent for eliminating
"difficult stains".
5.1.1. Upholsteries.
The fabric covering the stool upholstery must only be cleaned using the liquid detergent in the bottle sold by the dealer, using a
soft cloth to avoid any surface-chap and to guarantee better elasticity and smoothness of the surface.
NOTE.
As soon as the bottle of liquid runs out, it is recommended to order more from the closest sales and
maintenance centre.
5.1.2. Plastic or metal parts.
Plastic or metal parts (both painted and not) must be wiped with a cloth soaked in soap and water.
.
.
.
(
IF PRESENT
(
IF PRESENT

5. MAINTENANCE

– 16 –
).
).
Operating instructions
