4.0 Operation Elements / Connections and Display

1. Closed current converter (clamp for individual wires)
2. Clamp opening lever
3. Hold key for data memory
4. Measurement function selection switch (off / closed – / open current
converter)
5. LCD
6. Conductor type selection switch (single-wire / flat strip / multiple wire
conductors)
7. Open current converter (for multiple wire conductors)
8. Conductor Lock
1.
2.
3.
4.
5.
Display
9. AC voltage display
10. Data hold display
11. Measurement value
12. Display of measurement type
13. LOW battery (appears for nearly discharged battery)
