Standard Heat Conductor (part included in HCA UNITY1 package).
Plastic seal to be armed once HCA UNITY1 is assembled on Heat Conductor (part included in HCA UNITY1 pac-
kage and already pre-mounted on device).
Welding stud:
•
•

3.3. Aluminum Heat Conductor

3.4. Plastic Seal

3.5. Fixtures for flat and special radiators

M3x10, M3x12, M3x15
Shank nut M3

3.6. Sectional radiators

• Slide nut 33/51 (55mm)
• Slide nut 14/32 (36mm)
• Please mount with bolt M4x35 / M4x45 / M4x55 according to demand!

3.7. Tube radiators

• Slide nut for tube (36mm)
• Slide nut for tube (45mm)
• Please mount with bolt M4x35 / M4x45 / M4x55 according to demand!
Mounting with pair of
retractor
