Any complaints will be dealt with after the sales firm, the installer or the gas company has filed a complaint and sent a copy
of the purchase receipt with purchase date. Any repairs do not entitle you to extend the guarantee term. All consequential
damages or loss are excluded.

Installation instructions for Tali

Your gas fireplace may only be installed by a qualified installer and must be used in combination with the Wanders (M&G)
concentric channel system. Only then will the fireplace be approved in accordance with the European CE directive for appliances
burning gaseous fuels. We do not offer a warranty if the gas stove has been connected and/or installed incompletely or
incorrectly. The channel system consists of an inner channel with a diameter of 100 millimetres and an outside channel with
a diameter of 150 millimetres. The flue gases are exhausted outside via the inner 100-millimetre channel through natural
draught, while combustion air is supplied between the 100-millimetre and 150-millimetre channels.
The appliance may only be installed and connected by a certified installer in accordance with the standard gas installation
instructions and the installation requirements mentioned below. Furthermore, the national and local rules and regulations on
placing and using closed gas appliances shall be applicable. Only a certified installer has the authority to change the setting
values (in accordance with the requirements) and to carry out any other adjustments.
Before installing the appliance, the installer must check whether the information on the type tag of the fireplace
corresponds with the gas type and gas pressure to which the appliance is connected. If it does not match, you
are not allowed to connect the gas hearth.

Placing

The gas fireplace can be placed in a crack-free and/or mechanically ventilated home without difficulty. There is no need for
extra ventilation for combustion or for a smoke and fire vent. Waste gases are discharged by natural draught via the inner pipe
into the open. The oxygen needed for burning the fire is supplied from the space between the pipes. This is the reason that no
insulation must be placed between the inner and outer pipe.
The Tali must not be built into the wall, and must be placed on a floor that is solid enough to hold the appliance. The distance
from the Tali to the rear wall must be at least 10 cm, and there must be a free space of at least 20 centimetres to the right and
left side of the fireplace. Be sure to place the Tali on a solid floor plumb under the flue pipe.

Insulation

Due to the high temperatures of the exterior walls (up to approximately 150 °C or 300 °F) it is prohibited to have or to place
any combustible materials close to the channel system. The entire concentric pipe system should be encased with fireproof
material from the place where it is out of sight up to the outlet in the exterior wall. Ventilate the encased concentric pipe
system by placing a grate near the floor and the ceiling on every floor. Use universal wall clips with a diameter of 150 mm for
anchoring the concentric pipe system.
If an existing chimney is used, first make sure whether the chimney is sufficiently insulated and is wide enough
to accommodate the concentric pipe system. If the chimney was previously used as a wood-burning or coal-fired
stove, it must first be professionally cleaned. You must use special WANDERS connecting sets for connecting a
gas hearth to an existing chimney.

Gas connection

• Use a feed pipe with an approved G3/8" stop cock with coupling.
• De-aerate the supply pipe before fitting and fastening the appliance.
• Avoid tension on the operating valve and pipes to avoid gas leakage.
• Check if the connection is gastight.
