The AD011 (see fig. ) is designed as a universal external
interface for an addressable detector system. It connects a
generic detector with a dual loop (2-resistor configuration)
connection to the Advisor MASTER ATS1290 PID DGP. The
interface is equipped with one balanced input to connect the
alarm / tamper output of the detector and an open collector
output. This output can be used, for example, to enable / disable
the alarm LED on the detector (depending on the detector's
other functionalities, which can be programmed).
D C
EVICE ATEGORY
The AD011 is of the device category I/O, type 3 and will be
automatically recognised after learning the device into the
ATS1290 DGP. For more details about device categories and
types please refer to the ATS1290 manual.
M
OUNTING THE UNIT
Due to the free topology of the PID system, the AD011 can be
mounted some distance from the Point ID bus and detector.
1. Open the housing of the AD011.
2. Remove the PCB from the unit.
3. Position the unit where you want it mounted, e.g. on the
ceiling or wall.
4. Drill the necessary holes for fixing the housing.
5. Fix the housing to the ceiling or wall.
6. Reinstall the PCB.
CAUTION: When powering the system down/up, wait
for at least 1 minute to ensure a "clean boot".
C
ONNECTING THE UNIT
Connect the AD011 to the detector and Point ID bus (see fig.
1. Decide for a double or single resistor EOL configuration
2. Connect the detector alarm/tamper outputs via the
selected EOL resistor(s) to the input connectors 5 and 6.
M L
EMORY OCATION MAP FOR
Location Function
3 Zone types*
6 ATS-style output**
*Zone Types
The ATS1290 default value for input type is Double EOL (2).
Consequently the normal state is a single EOL resistor, for an
alarm state it is two EOL resistors in series, and for an input
tamper it can be either "Short" or "Open".
**ATS-style output
The output can be used to enable/disable the Alarm LED or
Walk Test LED on the detector. ATS output and zone
numbering are equivalent.
The default output number of the device equals the input number
when memory location 6 is set to 0 (default).

Installation Instructions

AD011
Decimal values
0 = Zone is off
1 = Single EOL
2 = Double EOL (default)
0
3. Connect the external power supply to connectors 3 and 4.
4. Connect the alarm LED enable connection from the
detector to the open collector output 7 (if applicable).
5. Connect the Point ID bus to connectors 1 and 2.
Important:
The Point ID bus in – (ground) must be coupled to the external
power supply in – (ground) to ensure correct operation!
A ,
DDRESS SETTING
Set the AD011 to its unique address on the Point ID bus. For
details, see figure
The address setting of the AD011 will immediately correspond
with zone number and output in the range of the ATS1290 DGP.
Refer also to the ATS1290 manual for the direct link to the zone
number (control panel).
For convenience the output also can be configured to connect
to any output in the DGP range (for more details see the
explanation at the and of the memory location map).
T ATS
HE OUTPUT
The walk test, for example, can be programmed through the
control panel by activating an output in the DGP range.
M
EMORY LOCATION MAP
Every PID device has its own characteristics concerning related
I/O lines or certain functionality of the device.
A total of 16 memory locations are reserved to configure the PID
devices. Only the first nine normally are user configurable. This
depends on the functionality of the particular device.
For the AD011 external PID interface only memory locations 3
and 6 matter.
On memory location 3 the zone type can be configured for
Single EOL, Double EOL (default) or the zone can be switched off
)
(the status will always be "Normal").
The ATS-style output can be configured on memory location 6.
For more details, please refer to the explanation at the end of
the Memory Location map.
Binary values
0000 0000 = Zone is off
0000 0001 = Single EOL
0000 0010 = Double EOL (default)
0000 0000
ATS output number that controls the AD011/AD111
output by means of "output on" / "output off" *
Please refer to the PID DGP manual for PID address settings
and zone numbering.
The output number on the AD011 can also be changed within the
DGP output range (e.g. DGP 1 output 17-32).
If the output of this device or all the outputs of similar devices on
the same DGP need to be programmed on for example output 32,
simply program memory location 6 of all those I/O devices to 32.
2
ZONE NUMBERS AND OUTPUT NUMBERS
.
