This unit is equipped with a main amplifier capable of handling 5.1 channel. Although up to 6 speakers can be
connected, it is possible to select the speaker mode that gives the best sound field effect according to the number and
size of speakers being used.
Before use, please set the speaker mode setting using "1 SPEAKER SET" on the SET MENU described on page 36.

Summary of SPEAKER SET Items 1A through 1E

Item
1A CENTER SP Selects the output mode according to whether or not a center speaker is
being used and its performance.
1B MAIN SP Selects the output mode according to the performance of the main
speakers.
1C REAR L/R SP Selects the output mode according to whether or not rear L/R speakers
are being used and their performance.
1D LFE/BASS OUT
Selects the speaker according to use for LFE signal output and low bass
signal.
1E MAIN LEVEL Selects the main speaker level.
20

SPEAKER MODE SETTINGS

Description
Control value (default
setting indicated in bold)
LRG/SML/NONE
LARGE/SMALL
LRG/SML/NONE
SWFR/MAIN/BOTH
Normal/–10 dB
