sauder.com

BEFORE MAKING ANY RETURNS TO THE STORE.

BEFORE MAKING ANY RETURNS TO THE RETAILER.

sauder.com/service

Visit

Prefer the phone? Give us a ring at

Customer Service is available Monday-Friday - 9 a.m. to 5:30 p.m. EST (except holidays)

Executive Desk

Boulevard Cafe Collection | Model 420701

Sauder.com

Share your journey!

to order replacement parts, view video assembly tips, or chat with a live rep.

1-800-445-1527

Sit and surf.

NOTE: THIS INSTRUCTION

BOOKLET CONTAINS IMPORTANT

SAFETY INFORMATION.

PLEASE READ AND KEEP FOR

FUTURE REFERENCE.

English pg 1-18

Français pg 19-21

Español pg 22-24

Lot # 531681

Purchased: __________________

09/09/19

Sommaire des Matières pour Sauder Boulevard Cafe Serie

Page 1 CONTACT US FIRST CONTACT US FIRST sauder.com sauder.com sauder.com BEFORE MAKING ANY RETURNS TO THE STORE. BEFORE MAKING ANY RETURNS TO THE RETAILER. sauder.com/service Visit to order replacement parts, view video assembly tips, or chat with a live rep. 1-800-445-1527 Prefer the phone? Give us a ring at Customer Service is available Monday-Friday - 9 a.m.
Page 2 Table of Contents Assembly Tools Required Part Identiﬁ cation No. 2 Phillips Screwdriver Tip Shown Actual Size Hardware Identiﬁ cation Assembly Steps 5-18 Français 19-21 Skip the power trip. Español 22-24 This time. Safety 25-26 Warranty Page 2 www.sauder.com/service 420701...
Page 3 MODESTY PANEL (1) DRAWER BOTTOM (3) LEFT UPRIGHT (1) SMALL DRAWER FRONT (1) LARGE DRAWER SIDE (4) TOP (1) LARGE DRAWER FRONT (2) LARGE DRAWER BACK (2) BOTTOM (2) SMALL DRAWER SIDE (2) LARGE DRAWER BOX FRONT (2) 420701 www.sauder.com/service Page 3...
Page 4 BLACK 1" HEX HEAD SCREW - 8 BLACK 7/8" HEX HEAD SCREW - 12 BLACK 3/4" MACHINE SCREW - 6 LARGE BLACK 1/2" FLAT HEAD SCREW - 12 SMALL BLACK 1/2" FLAT HEAD SCREW - 18 BLACK 3/8" MACHINE SCREW - 16 Page 4 www.sauder.com/service 420701...
Page 5 Look for this icon. It means a Step 1 video assembly tip is available at www.sauder.com/services/tips Assemble your unit on a carpeted ﬂ oor or on the empty carton å to avoid scratching your unit or the ﬂ oor. Remember: Righty tighty.
Page 6 Fasten the BACK (Y) to the LEFT UPRIGHT (V). Use two BLACK å 3/8" MACHINE SCREWS (34). BLACK 3/8" MACHINE SCREW (2 used in this step) BLACK 1-1/2" FLAT HEAD SCREW (2 used in this step) Page 6 www.sauder.com/service 420701...
Page 7 Step 3 Fasten the MODESTY PANEL (AA) to the LEFT UPRIGHT (V). å Use two BLACK 3/8" MACHINE SCREWS (34). BLACK 3/8" MACHINE SCREW (2 used in this step) 420701 www.sauder.com/service Page 7...
Page 8 Fasten the MODESTY PANEL (AA) to the RIGHT UPRIGHT (U). Use å two BLACK 3/8" MACHINESCREWS (34). BLACK 3/8" MACHINE SCREW (2 used in this step) BLACK 1-1/2" FLAT HEAD SCREW (2 used in this step) Page 8 www.sauder.com/service 420701...
Page 9 Fasten the BACK (Y) to the RIGHT END (S) and RIGHT å UPRIGHT (U). Use four BLACK 3/8" MACHINE SCREWS (34). BLACK 3/8" MACHINE SCREW (4 used in this step) BLACK 1-1/2" FLAT HEAD SCREW (4 used in this step) 420701 www.sauder.com/service Page 9...
Page 10 Fasten the SHELF (Z) to the LEFT END (T) and LEFT å UPRIGHT (V). Use four BLACK 3/8" MACHINE SCREWS (34). Now might be a good time to refresh your drink. BLACK 3/8" MACHINE SCREW (4 used in this step) Page 10 www.sauder.com/service 420701...
Page 11 Fasten the BOTTOMS (X) to the ENDS (S and T) and å UPRIGHTS (U and V). Tighten eight BLACK 1" HEX HEAD SCREWS (29) using the L-WRENCH (26). BLACK 1" HEX HEAD SCREW (8 used in this step) 420701 www.sauder.com/service Page 11...
Page 12 NOTE: The EXTENSION SLIDES will be used later for the DRAWERS. å Push the black lever up and hole pull the SLIDE from the RAIL. Open end LARGE BLACK 1/2" FLAT HEAD SCREW (12 used in this step) Open end hole Page 12 www.sauder.com/service 420701...
Page 13 Step 9 Turn eight ADJUSTABLE GLIDES (25) into the bottoms of å the ENDS (S and T) and UPRIGHTS (U and V). 420701 www.sauder.com/service Page 13...
Page 14 (4 used in Section 3) DRAWER BACK (EE) and SMALL DRAWER BOX FRONT (FF). Use four BLACK 1-9/16" FLAT HEAD SCREWS (27). NOTE: Be sure the DRAWER BOTTOM (GG) inserts into the å groove of the SMALL DRAWER SIDE (DD). Page 14 www.sauder.com/service 420701...
Page 15 OPEN END in the EXTENSION SLIDE. BLACK 3/4" MACHINE SCREW (2 used for the PULL) BLACK 7/8" HEX HEAD SCREW (4 used in this step) Open end SMALL BLACK 1/2" FLAT HEAD SCREW (6 used for the SLIDES) Open end 420701 www.sauder.com/service Page 15...
Page 16 Use four BLACK 1-9/16" FLAT HEAD SCREWS (27). (8 used in Section 3) NOTE: Be sure the DRAWER BOTTOM (GG) inserts into the å groove of the LARGE DRAWER SIDE (HH). Repeat this step for the other large drawer. å Page 16 www.sauder.com/service 420701...
Page 17 Repeat this step for the other large drawer. å BLACK 3/4" MACHINE SCREW (4 used for the PULLS) BLACK 7/8" HEX HEAD SCREW (8 used in this step) Open end Open end SMALL BLACK 1/2" FLAT HEAD SCREW (12 used for the SLIDES) 420701 www.sauder.com/service Page 17...
Page 18 NOTE: Please read the back pages of the instruction booklet for important safety information. å This completes assembly. Clean with a damp cloth. Wipe dry. å And to celebrate, why not share your success story at sauder.com or 35 lbs. each NOTE: To level the unit, turn the ADJUSTABLE GLIDES until your unit is level.
Page 19 DESCRIPTION QUANTITÉ REFERENCE DESCRIPTION QUANTITÉ conserver le livret pour future référence. Pour contacter Sauder en EXTRÉMITÉ DROITE ..........1 (ENSEMBLE DE GLISSIÈRE ILLUSTRÉ À PART) ce qui concerne cet EXTRÉMITÉ GAUCHE ..........1 GLISSIÈRE D'EXTENSION ........6 élément, faire référence MONTANT DROIT ............1 COULISSE D'EXTENSION ........6...
Page 20 Fixer l'EXTRÉMITÉ DROITE (S) et l'autre ARRIÈRE (Y) au DESSUS (W). Utiliser quatre VIS TÊTE PLATE 38 mm NOIRES (28). Fixer l'ARRIÈRE (Y) à l'EXTRÉMITÉ DROITE (S) et au MONTANT DROIT (U). Utiliser quatre VIS À MÉTAUX 9,5 mm NOIRES (34). Page 20 www.sauder.com/service 420701...
Page 21 TIROIR (JJ) et au DEVANT DE CAISSON DE GRAND TIROIR (KK). Utiliser quatre VIS TÊTE PLATE 40 mm NOIRES (27). REMARQUE : S'assurer que le FOND DE TIROIR (GG) s'encastre dans la rainure du CÔTÉ DE GRAND TIROIR (HH). Répéter cette étape pour l'autre grand tiroir. 420701 www.sauder.com/service Page 21...
Page 22 (JUEGO DE EXTENSIÓN SE MUESTRA POR SEPARADO) su referencia futura. Si necesita ponerse en EXTREMO IZQUIERDO ..........1 RIEL DE EXTENSIÓN ..........6 contacto con Sauder en PARAL DERECHO ............1 CORREDERA DE EXTENSIÓN ......6 cuanto a esta unidad, PARAL IZQUIERDO .............1 CORRIMIENTO DE ARCHIVERO.....4 reﬁ...
Page 23 SUPERIOR (W). Utilice cuatro TORNILLOS NEGROS DE CABEZA PERDIDA de 38 mm (28). Fije el DORSO (Y) al EXTREMO DERECHO (S) y al PARAL DERECHO (U). Utilice cuatro TORNILLOS NEGROS PARA METAL de 9,5 mm (34). 420701 www.sauder.com/service Page 23...
Page 24 TORNILLOS NEGROS DE CABEZA PERDIDA de 40 mm (27). NOTA: Asegúrese de que el FONDO DE CAJÓN (GG) ajuste dentro de la ranura del LADO DE CAJÓN GRANDE (HH). Repita este paso para el otro cajón grande. Page 24 www.sauder.com/service 420701...
Page 25 à Les téléviseurs peuvent être particulièrement un téléviseur. cet eff et. lourds. De plus, le poids et l’emplacement du tube image ont tendance à rendre les téléviseurs instables et enclins à tomber vers l’ a vant. 420701 www.sauder.com/service Page 25...
Page 26 Además, el peso y la ubicación del tubo de imagen tienden a causar la inestabilidad de televisores y propensa a volcarse hacia adelante. Page 26 www.sauder.com/service 420701...
Page 27 à compter de la date d'achat la première fois et qui sont signalés à Sauder dans les limites de couverture de la contre tout défaut de matériaux ou de fabrication des composantes de mobilier Sauder.
Page 28 BEFORE MAKING ANY RETURNS TO THE RETAILER. Dear Valued Customer: So, how did it go? Thanks so much for choosing Sauder® furniture. I hope the Set a world record for speed? purchase and assembly process was a positive experience Feeling good about yourself? and you feel good about the furniture you just built.
