Quick Guide
THANK YOU FOR BUYING A WHIRLPOOL PRODUCT.
In order to receive a more complete assistance, please
register your appliance on: www.whirlpool.eu/register
Before using the appliance carefully read Safety and Installation Instructions.
After installation, please remember to remove all transport protection parts from
the dishwasher.
CONTROL PANEL
1. ON-OFF/Reset button with indicator light
2. Program selection button
3. Salt refill indicator light
4. Rinse Aid refill indicator light
5. Program number and delay time indicator
6. Tablet indicator light
FIRST TIME USE
FILLING THE SALT RESERVOIR
The use of salt prevents the formation of LIMESCALE on the dishes and on
the machine's functional components.
• It is mandatory that the salt reservoir never be empty.
• It is important to set the water hardness.
The salt reservoir is located in the lower part of the dishwasher and must be
filled when the SALT REFILL indicator light
1. Remove the lower rack and unscrew the reservoir cap
(anticlockwise).
2. Position the funnel (see figure) and fill the salt reservoir
right up to its edge (approximately 1 kg); it is not unu-
sual for a little water to leak out.
3. Only the first time you do this: fill the salt reservoir
with water.
4. Remove the funnel and wipe any salt residue away from the opening.
Make sure the cap is screwed on tightly, so that no detergent can get into
the container during the wash program (this could damage the water
softener beyond repair).
Whenever you need to add salt, it is mandatory to complete the proce-
dure before the beginning of the washing cycle to avoid corrosion.
WATER SOFTENING SYSTEM
Water softener automatically reduces water hardness, consequently pre-
venting scale buildup on heater, contributing also to better cleaning effi-
ciency. This system regenerates itself with salt, therefore it is required
to refill salt container when empty.
PROGRAMS TABLE
Eco 50°- Program is suitable to clean normally soiled tableware, that for
this use, it is the most efficient programme in terms of its combined ener-
1.
gy and water consumption, and that it is used to assess compliance with
the EU Ecodesign legislation.
Intensive 65° - Program recommended for heavily soiled crockery, espe-
2.
cially suitable for pans and saucepans.
6 Sense® 50-60°- For normally soiled dishes with dried food residues.
th
3. Senses the level of soiling on the dishes and adjusts the program accord-
ingly.
Fast Wash&Dry 50° - Normally soiled crockery. Everyday cycle, that ensures
4.
optimal cleaning and drying performance in shorter time.
Half Load 55° - Ideal for washing a half load of lightly or normally soiled
5.
crockery.
Rapid 30' 45° - Program to be used for half load of lightly-soiled dishes
6.
with no dried food residues. Without drying.
Silent 50° - Suitable for night-time operation of the appliance. With the
7.
lowest noise.
Sanitizing 65° - Normally or heavily soiled crockery, with additional anti-
8.
bacterial wash. Can be used to perform maintenance of the dishwasher.
Prewash - Use to refresh crockery planned to be washed later.
9.
No detergent to be used with this program.
7. Display
8. Power Clean® indicator light
9. Power Clean® button
10. Delay button
11. START/Pause button with indicator light /
Tablet (Tab)
in the control panel is lit.
Programs description
PLEASE SCAN THE
QR CODE ON YOUR
APPLIANCE IN
ORDER TO HAVE
MORE DETAILED
INFORMATION
1
More information in the Daily Reference Guide on website.
Frequency of regeneration depends on water hardness level setting - regen-
eration takes place once per 6 Eco cycles with water hardness level set to 3.
Regeneration process starts in final rinse and finishes in drying phase, be-
fore cycle ends.
• Single regeneration consumes: ~3.5L of water;
• Takes up to 5 additional minutes for the cycle;
• Consumes below 0.005kWh of energy.
FILLING THE RINSE AID DISPENSER
Rinse aid makes dish DRYING easier. The rinse aid
dispenser A should be filled when the RINSE AID
D
REFILL indicator light
C
NEVER pour the rinse aid directly into the
appliance tub.
A
FILLING THE DETERGENT DISPENSER
To open the detergent dispenser use the opening device C. Introduce the
detergent into the dry dispenser D only. Place the amount of detergent for
pre-washing directly inside the tub.
If all-in-one detergents are used, we recommend using the TABLET button,
because it adjusts the program so that the best washing and drying results
are always achieved.
Usage of detergent not designed for dishwashers may cause
malfunction or damage to the appliance.
Available
options
*)
-
-
- -
2 3 4 5 6 7 8 9 10
in the control panel is lit.
Duration
Water
of wash
consumption
program
(litres/cycle)
(h:min)
**)
3:40 8.7
2:45 17.5
1:20 - 3:00 7.0 - 14.0
1:25 11.5
1:20 11.0
0:30 9.0
3:30 16.0
1:50 12.0
0:10 4.5
EN
11
Energy
consumption
(kWh/cycle)
0.67
1.60
0.70 - 1.10
1.10
1.00
0.50
1.15
1.30
0.01
