08
Install new adjustment plate using bolt from shifter in step 2
09
Remove the 4 countersunk bolts from the wheel plate
All manuals and user guides at all-guides.com
PARTS
1 x M5 30MM
1 x M5 WASHER
1 x M5 NUT
PARTS
4 x M6 COUNTERSUNK
BOLTS
4 x M6 NUTS
These nuts and bolts are
required for re-installation
10
10
Lift wheel plate off assembly
These parts are required for
re-installation
11
Rotate the adjustment knob anti-clockwise to loosen and remove
Video Instruction: bit.ly/nlrbuild
PARTS
NIL
PARTS
NIL
11
