ViewSonic TB2109HDH Guide Rapide

TB2109HDH
DLP Projector
4
MENU
BLANK
EXIT
ENTER
COLOR
SOURCE
MODE
1
TB2109HDH
DLP Projector
5
Screws: M4 x 8 (Max. L = 8 mm)
Unit: mm
293mm
2
2
1
3
4 5
MENU
EXIT
SOURCE
100-240 Vac SOURCE
50/60 Hz
• 16:9 image on a 16:9 screen
• 16:9 image on a 4:3 screen
3
MENU
EXIT
MENU BLANK
EXIT
ENTER
SOURC
COLOR
SOURCE
MODE
BLANK
ENT
ENTER
COLOR
MODE
(a) Screen Size (b) Projection distance
min.
inch mm inch mm inch
60 1524 77 1958 85
70 1778 90 2284 99
2032 103 2611 113
80
116 2937 127
90 2286
3263 141
100 2540 128
155
110 2794 141 3589
120 3048 154 3916 170
130 3302 167 4242 184
140 3556 180 4568 198
150 3810 193 4895 212
160 4064 206 5221 226
170 4318 218 5547 240
180 4572 231 5874 254
190 4826 244 6200 269
200 5080 257 6526 283
(a) Screen Size (b) Projection distance
min.
inch mm inch mm inch
60 1524 71 1797 78
70 1778 83 2097 91
80 2032 94 2396 104
90 2286 106 2696 117
100 2540 118 2995 130
110 2794 130 3295 143
120 3048 142 3594 156
130 3302 153 3894 169
140 3556 165 4193 182
150 3810 177 4493 195
160 4064 189 4792 208
170 4318 200 5092 221
180 4572 212 5391 233
190 4826 224 5691 246
200 5080 236 5990 259
There is 3% tolerance among these numbers due to optical component variations. It is
recommended that if you intend to permanently install the projector, you should physically
test the projection size and distance using the actual projector in situ before you permanently
install it, so as to make allowance for this projector's optical characteristics. This will help you
determine the exact mounting position so that it best suits your installation location.
16:9 image on a 16:9 Screen
(c) (d) Vertical offset
Image height
max. min. max.
mm inch mm inch mm inch mm
2154 29 747 2.4 59.8 2.4 60
2513 34 872 2.7 69.7 2.7 70
2872 39 996 3.1 79.7 3.1 80
3231 44 1121 3.5 89.7 3.5 90
3589 49 1245 3.9 99.6 3.9 100
3948 54 1370 4.3 109.6 4.3 110
4307 59 1494 4.7 119.5 4.7 120
64 1619 5.1 129.5 5.1 130
4666
1743 5.5 139.5 5.5 139
5025 69
5.9 149.4 5.9 149
5384 74 1868
159.4 6.3 159
5743 78 1992 6.3
6.7 169
6102 83 2117 6.7 169.4
7.1 179
6461 88 2241 7.1 179.3
6820 93 2366 7.5 189.3 7.5 189
7179 98 2491 7.8 199.2 7.8 199
16:9 image on a 4:3 Screen
(c) (d) Vertical offset
max. Image height min. max.
mm inch mm inch mm inch mm
1977 27 686 2.2 55 2.2 55
2306 32 800 2.5 64 2.5 64
2636 36 914 2.9 73 2.9 73
2965 41 1029 3.2 82 3.2 82
3295 45 1143 3.6 91 3.6 91
3624 50 1257 4.0 101 4.0 101
3954 54 1372 4.3 110 4.3 110
4283 59 1486 4.7 119 4.7 119
4613 63 1600 5.0 128 5.0 128
4942 68 1715 5.4 137 5.4 137
5272 72 1829 5.8 146 5.8 146
5601 77 1943 6.1 155 6.1 155
5930 81 2057 6.5 165 6.5 165
6260 86 2172 6.8 174 6.8 174
6589 90 2286 7.2 183 7.2 183
