Smart AC 200W USB+ by Wagan Tech
™
Thank you for purchasing Smart AC
With normal care and proper treatment, it will provide years of reliable
service. It is important to read, understand, and comply with these
instructions before using this inverter. Keep this User's Manual for future
reference.

General Information

This inverter is powered from a 12 volt DC source and provides 120
volts AC 60 Hz through two North American standard outlets to AC
appliances up to 200 watts. The AC waveform is a modified sine wave
(MSW), which approximates the sine wave of household electrical
service. An attached DC power cord connects to a 12 V DC cigarette
lighter socket. There is a USB power port that can be used to charge
cell phones, PDAs, and MP3 players. Safety features include automatic
shutdown in the event of overheat, overload, under voltage, and over
voltage conditions.
This inverter has features that will prevent your battery from being
completely discharged. An audible alarm will sound when the battery
voltage is 10.5 volts. If you hear this alarm we recommend operating
your engine for 10-20 minutes to recharge the vehicle's battery.
www.wagan.com
1
200W USB+ by Wagan Tech.
™
User's Manual—Read before using this equipment
WARNINGS
• Keep the inverter away from children.
• Do not operate the inverter with wet hands because of electrical shock
hazards.
• This device produces a voltage similar to wall outlets at home and
should be treated with the same caution.
Operating Environment & User Responsibility
• Unplug the inverter when starting the vehicle's engine.
• Unplug or disconnect the inverter when it is not in use.
• Keep at least one inch of clearance around the inverter for air flow.
• Keep the inverter and all cords dry.
• Secure the inverter to keep it stationary while a vehicle is moving.
• Know the wattage requirements of your appliances. Appliance total
wattage can not exceed 200 watts.
• Make sure the inverter is connected to the correct voltage and polarity.
• Do not connect the inverters AC output to another AC power source.
Damage will result, voiding the inverter's warranty.
• The 12 volt supply must provide between 10 volts to 14.5 volts DC.
• Do not use an extension cord between the DC power source and the
DC input of the inverter. An extension cord can create a voltage drop
that can reduce efficiency and output.
