Boost -INBOX300 Manuel D'utilisation page 4

6. Select OK or YES to pair this unit with your phone or music player.
7. If protected, enter 0000 for passkey steady blue light indicates successful connection.
8. Press the DISCONNECT key on the remote to disconnect the Bluetooth.
USB Player
This unit has two USB jacks. Press the INPUT A key to select USB A, then you can insert a USB to play music. Press the
INPUT B key to select USB B, then you can insert the other USB to play music.
When two USB are inserted at the same time, you can play music at the same time.
Important: The USB port is intended for data transfer only; other devices cannot be used with this USB connection.
The use of USB extension cords is not recommended.
Protection of the battery
1. When the unit operates on battery, it can't be set into standby mode.
2. When the battery is low, the system prompts "LOW POWER" and the POWER lamp blinks.
3. When the battery is almost exhausted, the system prompts "NO POWER" and the POWER lamp flashes. After 1
minute, the system will stop. The red LED on the control panel is on when the battery is charged. It starts flashing
when the battery runs low.
REAR PANEL
1. POWER
Switch power BATT 12V INPUT, AC
INPUT or BATT off.
2. LINE OUT AUDIO JACK
Connect to LINE OUT signal output
jack.
3. DC 15V INPUT: To connect to
external power DC 15V.
4. FM ANTENNA
FRONT PANEL
1. LED DISPLAY
2. VOLUME/MULTI: Rotate the knob to
adjust the volume and press this key to
choose different music effect.
3. DJ MODE: Press this key to choose
different dj mode.
4. USB B : Press this key to choose
previous music with USB B
5. USB B : Press this key to choose next
music with USB B
6. USB B VOLUME: This is used to adjust
the volume with USB B
7. USB B : Press this key to choose
play/pause music with USB B
8. INPUT USB B: Press this key to choose
USB B input mode.
9. USB B input jack
10. GUITAR VOLUME
11. MIC VOLUME
12. ECHO
©LOTRONIC 2016 BOOST-INBOX300 4
