• Do not operate the product at, on or in the vicinity of open flames (e.g. candles)!
• Do not bend using force!
• To avoid damage, do not bend or knot cables over sharp edges or corners!
• When installing in rooms with bath or shower: Observe guideline VDE 0100 Part 701!
SCOPE OF DELIVERY
Check the delivery for completeness and perfect condition.
In the case of missing parts or damage:
• do not mount the unit!
• do not put the unit into operation!
• make a complaint to the supplier.
The deliver consists of:
• Product
• Mounting material (2x screws, 2x dowels)
• Instructions
TECHNICAL DATA
• These products contain light sources of energy efficiency class F
• Illuminant: SMD LEDs
• Colour temperature: 4000K
• Colour rendering index (Ra/CRI): ≥ 80
• LED service life: 25000h
• Beam angle: ≥120°
• IP protection class: IP20
• Protection class: II (S6)
• Ambient temperature: 0°C – 25°C
• Supply line: 160cm / H03VVH2-F 2x0,75mm²
Type Performance
TL4040-6W 6W
TL4040-9W 9W
INSTALLATION
• Please refer to the drawings for the installation steps.
• Type of mounting of the luminaire (S9):
a) on the ceiling.
b) horizontally on the wall.
c) in the horizontal corner, lamp on the side and below.
d) in the U-profile.
e) suitable for installation in and on furnishings e.g. furniture. In the specified mounting method, the
luminaires may be mounted on furnishings made of materials with unknown fire behaviour, even if
these are coated, painted or veneered.
CLEANING
• Allow the luminaire to cool down sufficiently!
• Before cleaning, unplug the product from the power point or disconnect it from the mains supply!
• Clean with a dry or slightly moist, clean, lint-free cloth and a mild detergent if required. Do not use cleaners that
contain abrasives or solvents.
Nominal data
230V~/50Hz/0,045A
230V~/50Hz/0,066A
Lumen Luminous
efficacy
480lm 80 lm/W
750lm 83 lm/W
Dimensions Weight
(WxHxD)
500x20,5x68mm 437g
750x20,5x68mm 570g
