GE RAG26AA Instructions D'installation page 2

STEP 2: Aligning Grille with Wall Sleeve
Firmly grasp grille by holding the grille with one hand
and the ribbon handle with the other hand. Tilt grille to
insert through wall sleeve and out the back of the wall
sleeve. Make sure the tabs are in place
Tabs
WARNING
When installing grille, be sure to
securely hold with 2 hands to prevent it from falling and
causing injury or damage.
Installation Instructions
Tabs
2
STEP 3: Mounting Grille to Wall Sleeve
Line up the 4 mounting tabs on the grille, making sure
their vertical position and tighten the screws fully.
STEP 4: Securing Grille
Tighten the four mounting screws with 1/4" nut driver to
secure the grille tabs to the wall sleeve.
Mounting
Screws
Remove the ribbon handle after the installation is
complete.
Rear Side Mounting
Flange Screws
31-5000794 Rev. 0 02-24
