Matco Tools ACSB300 Mode D'emploi

WARNING
PLEASE NOTE THE FOLLOWING SAFETY POINTS:
Maximum rated capacity: 300 lbs
Read, study, understand & follow all instructions before using.
Do not exceed weight capacity
Inspect before every use. Do not use if parts are loose or damaged.
Wear gloves when lifting edges
Keep children away from unit
Do not sit on edge of seat. Stool can tilt or tip over causing damage or
personal injury
Do not stand on stool or use as a cart.
Product is designed to roll easily on flat surfaces and should not be
used on uneven or inclined surfaces.
Do not use (or modify) this product for any other purpose than that for
which it was designed.
Do not remove any labels. Replace any damaged labels.
Do not expose to heat as some parts of this product are under pressure.
Failure to heed these warnings may result in personal injury and/or
property damage.
WARNING: This product can expose you to chemicals including nickel which is known
to the State of California to cause cancer and birth defects or other reproductive harm.
For more information go to www.P65Warnings.ca.gov.
ADVERTENCIA: Este producto le podrá exponer a ciertos químicos, para incluir el
ASSEMBLY
níquel, conocidos en el Estado de California por ocasionar cáncer y defectos
1. Start with the tool tray(#2) and metal frame assembly(#8) and flip upside down. congénitos u otros daños a la reproducción. Para mayores informes, visite:
www.P65Warnings.ca.gov.
CAUTION
AVERTISSEMENT: Ce produit peut vous exposer à des produits chimiques y compris
le nickel, reconnu par l'État de la Californie comme causant le cancer et des
anomalies congénitales ou d'autres effets nuisibles sur la reproduction. Pour de plus
amples informations, aller à www.P65Warnings.ca.gov.
2. Use the included flat wrench to install each caster wheel(#5). Pay attention to fully install the caster(#5)
3. After installing all four caster wheels(#5) flip back over and double check that the wheels(#5) are level
4. Insert the seat post cylinder(#6) and press firmly
5. Place the seat(#1) upside down and assemble the metal seat
bracket(#7) by using the supplied fasteners, wrench, and hex key.
6. Place the seat assembly on the seat post cylinder(#6) and
press firmly.
7. Use the handle to adjust the height of the seat position.
Item Parts No Parts Name
1 RSACSB01 SEAT (BLACK)
2 RSACSB02 ORGANIZE TRAY (BLUE)
4 RSACSB04 CUP HOLDER SET (2 PIECES) (BLUE)
5 RSACSB05 4" SWIVEL WHEEL SET (4 PIECES)
6 RSACSB06 HYDRAULIC CYLINDER
7 RSACSB06 PLATE AND
RELEASE LEVER W/HARDWARE
8 RSACSB08 METAL FRAME
ACSB300
PLATAFORMA RODANTE AJUSTABLE
SOMMIER ET TABOURET RÉGLABLE
Qty
1
1
1
1
1
1
1
1
ACSB300
ACSB300
ADJUSTABLE CREEPER STOOL
Copyright © 2023
All rights reserved.
06/01/23
