6. Autofocus
(This function is only available on machines with autofocus accessories)
6.1 Precautions:
6.1.1 When using a chuck or a roller, or when engraving/cutting irregular objects (such as pebbles) or soft materials (such as office paper, kraft paper,
cashmere fabric, denim), it is recommended to use a fixed-focus tool for manual focusing.
6.1.2 After the lower limit autofocus fails, the Z-axis automatically rises a certain distance.
6.2 Operation method:
6.2.1 Manually or using Lightburn to move the Z-axis position (pay attention not to slide the Z-axis slider to the bottom). Refer to the diagram below for
controlling Z-axis movement in Lightburn.
6.2.2 After aligning the bottom of the laser with the object to be tested, fix it in place. If there is a prompt indicating that the maximum range has been
exceeded, click "close". If the prompt continues to appear, slightly raise the laser.
The machine exceeds the maximum range of motion
5
