OHAUS Ranger R41ME3 Mode D'emploi page 6

EN-4
Specifications:
MODEL
Capacity x Readability
(Max x d non-approved)
Maximum Displayed
Resolution
Capacity x Readability
(Max x e approved)
Approved Resolution
Repeatability
Linearity
6. COMPLIANCE
Compliance to the following standards is indicated by the corresponding mark on the product.
Mark Standard
This product complies with the EU Directives 2014/30/EU (EMC), 2014/35/EU (LVD) and 2014/31/EU
(NAWI). The EU Declaration of Conformity is available online at www.ohaus.com/ce.
This product complies with the EU Directive 2002/96/EC (WEEE). Please dispose of this product in
accordance with local regulations at the collecting point specified for electrical and electronic equipment.
For disposal instructions in Europe, refer to www.ohaus.com/weee.
Verified weighing instruments
When the instrument is used in trade or a legally controlled application it must be set up, verified and sealed in accordance
with local weights and measures regulations. It is the responsibility of the purchaser to ensure that all pertinent legal
requirements are met.
Weighing Instruments verified at the place of manufacture bear the following supplementary metrology marking on the
descriptive plate.
Weighing Instruments to be verified in two stages have no supplementary metrology marking on the descriptive plate. The
second stage of conformity assessment must be carried out by the applicable weights and measures authorities.
If national regulations limit the validity period of the verification, the user of the weighing instrument must strictly observe the
re-verification period and inform the weights and measures authorities
As verification requirements vary by jurisdiction, the purchaser should contact their local weights and measures office if they
are not familiar with the requirements.
R41ME3 R41ME6
3 kg x 0.0001 kg 6 kg x 0.0002 kg
3000 g x 0.1 g 6000 g x 0.2 g
6 lb x 0.0002 lb 15 lb x 0.0005 lb
96 oz x 0.004 oz 240 oz x 0.01 oz
3 kg x 0.001 kg 6 kg x 0.002 kg
3000 g x 1 g 6000 g x 2 g
6 lb x 0.002 lb 15 lb x 0.005 lb
96 oz x 0.04 oz 240 oz x 0.1 oz
0.0002 kg 0.0005 kg
0.0002 kg 0.0005 kg
R41ME15
15 kg x 0.0005 kg
15000 g x 0.5 g
30 lb x 0.001 lb
480 oz x 0.02 oz
1:30000
15 kg x 0.005 kg
15000 g x 5 g
30 lb x 0.01 lb
480 oz x 0.18 oz
1:3000
0.001 kg
0.001 kg
TM
RANGER 3000 SERIES
R41ME30
30 kg x 0.001 kg
30000 g x 1 g
60 lb x 0.002 lb
960 oz x 0.04 oz
30 kg x 0.01 kg
30000 g x 10 g
60 lb x 0.02 lb
960 oz x 0.36 oz
0.002 kg
0.002 kg
