INSTALLATION
1
DESK
1a Place the wheel base on your desk and
ensure the feet at the bottom are aligned
against the edge
1b Insert the clamp into the hole at the front
1c Tighten the clamp by adjusting
the screw handle
Once the clamp has come into contact
with the desk, you only need between
a half and one full turn of the handle to
achieve the correct level of clamping
Do not overtighten
NOTE:
– Also be aware of the construction of your
desk and its suitability for clamping a
high-torque wheel to it Some desks use
a hollow-core construction, for example,
where you have a top piece of material
and a bottom piece Those pieces are
likely to be thin and are unlikely to stand
up to the forces applied when the wheel is
clamped in place Logitech recommends
only clamping your PRO Wheel to a desk
made from a solid material, such as MDF
or wood
1a
1b
4 ENGLISH
< 50 mm (1.97 in)
1c
