(1) Parameter selection button (left)
for selecting the parameters listed below.
The corresponding indicator lights up when a parameter is
selected.
Material thickness *)
in mm or inches
Current *)
current in A
Before the start of welding, the machine automatically dis-
plays a standard value based on the programmed parame-
ters. During welding, the actual value is displayed.
Wire feed speed *)
in m/min or ipm
Special function
can only be selected if the SP welding process and the
LSC or PMC special program has first been selected using
the "Welding process" button (5).
The following process control parameters can be selected
and adjusted on all devices:
-
-
As soon as F1 is selected, the current adjustable process
control parameter is marked with an arrow on the display.
Press the "Parameter selection" button (left) (1) again to
select the second process control parameter.
The following special functions can be selected depending
on the configuration.
*) = Synergic parameter
When a synergic parameter is changed, the synergic func-
tion automatically changes all other synergic parameters
to match.
Penetration stabiliser
Arc length stabiliser
