d) Pairing the headsets using NFC
• Enable NFC on your smartphone.
Observe also the operating instructions for your smartphone.
• Switch the headset on.
• Hold the headset with top side (3) against the rear side of your smartphone. Move
your smartphone slowly downwards above the headset.
• Once the headset is detected by your smartphone, a message appears on the dis-
play. Confirm the message accordingly by OK.
To connect the headset via NFC with your smartphone later, just repeat the
described procedure again.
Use
a) Making a call
• Use your smartphone as usual. If your headset is connected with your smartphone,
the call is transmitted to the headset automatically.
b) Accepting a call
• To accept a call, just press the answer-call button (2).
c) Ending a call
• To end a call, press the button 2 again.
d) Rejecting a call
• To reject a call, press and hold the button 2 for approx. 3 seconds, until you hear a
peep sound in the earphone (7).
e) Redialling
• Press the button 2 briefly two times in a row. You will hear a brief peep sound in the
earphone (7) and the last dialled number will be dialled again automatically.
f) Muting the microphone
• To mute microphone during a talk, press and hold the volume button (6) for approx.
3 seconds until you hear a peep sound.
• To activate the microphone again, press the same button 6 and hold again for
3 seconds.
g) Switching between headset and phone during a call
• To switch between headset and phone during a talk press and hold the answer-call
button (2) for approx. 3 seconds until you hear a deep sound.
h) Making a call using voice control
The headset supports voice control as well. To enable the function, your smartphone
should also support voice control.
• Activate the voice control on your smartphone and switch it into the speakerphone
mode.
• If there are no active calls, press and hold the volume button (6) for approx. 3 sec-
onds until you hear a brief peep sound.
• Now you can give instructions e.g. to call a person through the headset.
i) Setting the earphone sound level
• To increase the volume during a talk or while listening to music, press the button
5 until the desired sound level is reached.
• To reduce the volume use the button 6.
j) Listening to music
You can also listen to music through your earphone.
• Open the music App on your smartphone. Usually, music starts playing on the
headset automatically. If this is not the case, select the Bluetooth
"TWNT-BH803" in the App for playback.
• To start or pause playback, press the button 2.
• To go to the next track, press and hold the volume + button for approx. 3 seconds.
• To return to the previous track, press and hold the volume - button for approx.
3 seconds.
All manuals and user guides at all-guides.com
Maintenance and cleaning
The product is maintenance-free. Maintenance or repair work may be performed only
by qualified personnel or a specialised repair shop. The product contains no parts that
require servicing. Therefore, do not open it.
To clean the outside of the product, a dry, soft and clean cloth is sufficient. Do not ap-
ply too much pressure on the housing; this could result in scratch marks. To clean the
earphone (7), the rubber sheath can be removed carefully.
Disposal
Declaration of Conformity (DOC)
We, Conrad Electronic SE, Klaus-Conrad-Straße 1, D-92240 Hirschau, hereby declare
that this product conforms to the fundamental requirements and other relevant regula-
tions of the 1999/5/EC directive.
Technical data
Power supply ...................................... by permanently built-in Li-polymer rechargeable
Power consumption........................... max. 15 mA
Battery ................................................. rechargeable Li-polymer battery, 3.7 V/DC, 65 mAh
Recharging .......................................... via the enclosed micro-USB cable
Talk time ............................................... up to 4 hours
Standby time ....................................... up to 100 hours
Music playback time ......................... up to 4 hours 20 minutes
Transmission standards .................... Bluetooth
Range ................................................... max. 10 m
Supported operating systems .......... Windows
Dimensions (L x W x D) ..................... approx. 55 x 17 x 26 mm
Weight .................................................. approx. 10 g
Operating conditions ......................... -10 °C to +50 °C; 0% to 85% relative humidity
Storage conditions............................. -10 °C to +50 °C; 0% to 90% relative humidity
device
®
Do not use abrasive cleaning agents, rubbing alcohol or other chemical so-
lutions, which may damage the casing or even impair operation.
The product must not be disposed of in the household waste!
Dispose of the waste product in accordance with the applicable legal regu-
lations.
The Declaration of Conformity (DOC) for this product can be found at
www.conrad.com.
This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com).
All rights including translation reserved. Reproduction by any method, e.g. photocopy, microfilming, or the capture in electronic data
processing systems require the prior written approval by the editor. Reprinting, also in part, is prohibited. This publication represent
the technical status at the time of printing.
© Copyright 2015 by Conrad Electronic SE.
battery
4.0; NFC
®
XP from SP1 (only 32 bit); Windows
®
Vista , Windows 7, Windows
TM ® ®
10 (32 and 64 Bit); MacOS 10.7 and higher; Linux;
Android 3.x and higher; Apple iOS from version
TM
4.0; Blackberry 9530
8, Windows
®
