  • Page 1 All manuals and user guides at all-guides.com KITs SAT 650 (Astra, Hot Bird, Atlantic Bird, Sirius, Hispasat ...) © Copyright, Televés S.A.
  • Page 2 All manuals and user guides at all-guides.com...
  • Page 3 All manuals and user guides at all-guides.com Recepción KITS 650 / 800 TV Satélite Por favor, antes de comenzar con la instalación, lea con atención este manual y siga paso a paso sus instrucciones. ELEMENTOS DEL KIT TV/SAT AUDIO Antena Conversor LNB Receptor Satélite...
  • Page 4 All manuals and user guides at all-guides.com Recepción KITS 650 / 800 TV Satélite COMO MONTAR LA ANTENA Fig. 5 Fig. 6 Fig. 4 Fig. 7 Fig. 8 Fig. 9 Fig. 10 Fig. 11 Fig. 12...
  • Page 5 All manuals and user guides at all-guides.com Recepción KITS 650 / 800 TV Satélite COMO ORIENTAR LA ANTENA Fijar la elevación (ángulo "a"). Comience situando la antena, mediante la escala graduada, en el ángulo "a" correspondiente al lugar en el que se encuentre, usan- do para ello los mapas de orienta- ción.
  • Page 6 All manuals and user guides at all-guides.com Recepción KITS 650 / 800 TV Satélite CONEXIONES A REALIZAR LNB IN DC13/17V AUDIO LNB IN 230VAC~ DC13/17V DECODER 50Hz/30W Fig. 18 Fig. 17 AUDIO LNB IN 230VAC~ DC13/17V DECODER 50Hz/30W Fig. 19 Realice las interconexiones entre el conversor LNB y el receptor mediante un cable de calidad del tipo T100.
  • Page 7 All manuals and user guides at all-guides.com Recepção KITS 650 / 800 TV Satélite Por favor, antes de comenzar a instalação, leia com atenção este manual e siga passo a passo as suas instruções. ELEMENTOS DO KIT TV/SAT AUDIO Antena Conversor LNB Receptor Satélite...
  • Page 8 All manuals and user guides at all-guides.com Recepção KITS 650 / 800 TV Satélite COMO MONTAR A ANTENA Fig. 5 Fig. 6 Fig. 4 Fig. 7 Fig. 8 Fig. 9 Fig. 10 Fig. 11 Fig. 12...
  • Page 9 All manuals and user guides at all-guides.com Recepção KITS 650 / 800 TV Satélite COMO ORIENTAR A ANTENA Fixar a elevação (ângulo "a"). Comece por situar a antena, utili- zando a escala graduada, em que o ângulo "a" corresponde ao local em que será...
  • Page 10 All manuals and user guides at all-guides.com Recepção KITS 650 / 800 TV Satélite LIGAÇÕES A EFECTUAR LNB IN DC13/17V AUDIO LNB IN 230VAC~ DC13/17V DECODER 50Hz/30W Fig. 18 Fig. 17 AUDIO LNB IN 230VAC~ DC13/17V DECODER 50Hz/30W Fig. 19 Efectue as interligações entre o conversor LNB e o receptor através de um cabo de qualidade do tipo T100.
  • Page 11 All manuals and user guides at all-guides.com Reception KITS 650 / 800 TV Satellite Avant de commencer l’installation, lisez attentivement ce manuel et suivez petit à petit les instructions. ELEMENTS DU KIT TV/SAT AUDIO Antena Convertisseur LNB Récepteur Satellite 650 ou 800...
  • Page 12 All manuals and user guides at all-guides.com Reception KITS 650 / 800 TV Satellite COMMENT INSTALLER L’ANTENNE Fig. 5 Fig. 6 Fig. 4 Fig. 7 Fig. 8 Fig. 9 Fig. 10 Fig. 11 Fig. 12...
  • Page 13 All manuals and user guides at all-guides.com Reception KITS 650 / 800 TV Satellite COMMENT ORIENTER L’ANTENNE Fixer l’élévation (angle "a"). A l’aide de l’echelle graduée, com- mencez par situer l’antenne sur l’angle "a" qui correspond au lieu où elle se trouve. Pour cela, utilisez les cartes d’orientation.
  • Page 14 All manuals and user guides at all-guides.com Reception KITS 650 / 800 TV Satellite BRANCHEMENTS A EFFECTUER LNB IN DC13/17V AUDIO LNB IN 230VAC~ DC13/17V DECODER 50Hz/30W Fig. 18 Fig. 17 AUDIO LNB IN 230VAC~ DC13/17V DECODER 50Hz/30W Fig. 19 Réalisez les inter-connexions entre le convertisseur LNB et le récepteur à...
  • Page 15 All manuals and user guides at all-guides.com Reception KITS 650 / 800 TV Satellite Before beginning the installation, please read this manual carefully and follow the instructions step by step. KIT ELEMENTS TV/SAT AUDIO Antenna Satellite Receiver 650 or 800...
  • Page 16 All manuals and user guides at all-guides.com Reception KITS 650 / 800 TV Satellite MOUNTING THE ANTENNA Fig. 5 Fig. 6 Fig. 4 Fig. 7 Fig. 8 Fig. 9 Fig. 10 Fig. 11 Fig. 12...
  • Page 17 All manuals and user guides at all-guides.com Reception KITS 650 / 800 TV Satellite ORIENTATION Elevation angle (angle "a"). Start by placing the antenna in the “a” angle position according to where you live, using the orienta- tion maps. Fig. 14 shows an elevation angle of 33°.
  • Page 18 All manuals and user guides at all-guides.com Reception KITS 650 / 800 TV Satellite CONNECTIONS LNB IN DC13/17V AUDIO LNB IN 230VAC~ DC13/17V DECODER 50Hz/30W Fig. 18 Fig. 17 AUDIO LNB IN 230VAC~ DC13/17V DECODER 50Hz/30W Fig. 19 Connect the LNB and the receiver by using a T100 cable.
  • Page 19 All manuals and user guides at all-guides.com...
  • Page 20 All manuals and user guides at all-guides.com...
  • Page 21 All manuals and user guides at all-guides.com...
  • Page 22 All manuals and user guides at all-guides.com...
  • Page 23 All manuals and user guides at all-guides.com...
  • Page 24 Tenerife Las Palmas MELILLA Tel.: (+39)-0251650604 (RA) Fax: (+39)-0255307363 televes.it@televes.com TELEVES MIDDLE EAST FZE P.O. Box 17199 JEBEL ALI FREE ZONE DUBAI, UNITED ARAB EMIRATES Tel.: 9714 88 343 44 Fax: 9714 88 346 44 televes.me@televes.com Rúa B. de Conxo, 17...
