To re-install the glass shelves, tilt the front of
the shelf up and guide the shelf hooks into
the slots at a desired height (1). Then lower
the front of the shelf so that the hooks can
drop into the slots (2).
The refrigerator compartment is also
provided with a foldable shelf. It can be
folded as required.
To fold the shelf, hold the removable
glass(N) and lift it up slightly, then push it
slightly in the direction of the arrow.
N
To unfold the shelf, hold the removable
glass(N) and pull it out slightly in the
direction of the arrow until it can't move.
N
Vegetable and fruit crispers
The crispers are suitable for storage of
vegetables and fruit. To take them out,
open the door to the final location first.
Then pull out the drawer and tilt up the
front of the crisper after moving slightly
in the direction of the arrow.
1
2
Using the freezer compartment
The freezer compartment is provided with
an upper drawer, a lower drawer and an
ice box. To remove all of them, refer to
page 8 for disassembly instruction.
Press ICE On/Off to turn the ice maker On
and Off. The Ice Maker icon is " " illuminated
when the ice maker is functioning.
On/Off
Following installation, allow 24 hours to
produce the first batch of ice. Discard
the first three batches of ice produced.
Allow 2 to 3 days to fill the ice storage
container.
If the ice in the ice container clumps,
break up ice using a plastic utensil and
discard. Do not use a sharp tool to break
up the ice. This can cause damage to
the ice container.
Do not store any items other than ice in
the ice storage container.
Motor
Feeler Arm
Ice
Ice Storage
Container
16
