CARE AND MAINTENANCE
2. REPLACING THE DRIVE BELTS
Remove the 5 screws that secure the left side
cover (Q) to the frame of the snow thrower.
Remove the side cover.
Remove the old belt (R) from the small pulley
(S) and large pulley (T).
Loop one end of the new belt over the small
pulley.
Rotate the impeller with the left hand while
positioning the belt on the large pulley with the
right hand.
Install the left side cover and secure it using
the 5 screws.
All manuals and user guides at all-guides.com
16
2
Q
5 Screws
T
S
R
