Installation Instructions
1. Connect HDMI source devices to the HDMI input ports via
HDMI cables.
2. Connect an HDMI display to the HDMI out port via an HDMI
cable.
3. Connect an audio system to the audio out port via an audio
cable.
4. Power on all the devices.
5. Use front panel or IR remote handset to control the
switcher.
Audio/Video Output
HDMI
In 1
Apple TV
Audio/Video Input
All manuals and user guides at all-guides.com
HDMI HDMI
In 2 In 3
Xbox STB
5
Display
HDMI
Out
HDMI
In 4
Blu-ray Player
Audi o System
Audi o
Out
