RADION TriTech
RFDL -11/RFDL -11-A
Installation Guide
1
4
INT
STD
MAX
- 6
- 10
6
+
AA Alkaline,
1.5 VDC
-
© 2016 Bosch Security Systems, Inc.
Pet Friendly
1 dog ≤ 45 kg (100 lbs)
2 dogs ≤ 27 kg (60 lbs)
or up to 10 cats
Not tested by UL
2 - 2.4 m
(6.5 - 7.8 ft)
UL - only model RFDL-11-A is evaluated by UL
UL639: Standard for Intrusion-Detection Units
(Pet Friendly Immunity is not a feature of UL639)
FCC, Part 15
2
INT
STD
MAX
- 6
- 10
6.1 m (20 ft)
2 m (6.5 ft)
2.1 m (6.9 ft)
2.4 m (7.8 ft)
EN
7
EN
EN 50131-2-4
EN 50131-5-3
Grade 2
Environment Class II
INCERT
B-509-0069
RFDL-11 only
3
- 6
- 10
INT
STD
INT
STD
10.7 m (35 ft)
-7°
-5°
-9°
-6°
-10°
-7°
5
72 mm (2.83 in)
138 mm
(5.43 in)
Duracell MN1500 AA Alkaline 6 VDC
Panasonic AM-3PIX AA Alkaline 6 VDC
P/N: F.01U.261.834 - B810
P/N: F.01U.261.835 - RFRC-OPT
Functional range: -10°C to +49°C (+14°F to +120°F)
UL only: 0°C to +49°C (+32°F to +120°F)
EN 50130-5 Class II only:-10°C to +40°C (+14°F to +104°F)
INT
STD
MAX
- 6
- 10
EN
8
F.01U.261.815 | 07 | 2016.05 | 1
64 mm (2.52 in)
433.42 MHz
0 - 93% Non-condensing
humidity
=
-5.0 °
- 6
- 10
