ASME A112.18.1 / CSA B125.1
ICC/ANSI A117.1
Model/Modelo/Modéle
T2792 & T4792
Series/Series/Seria
Addison™
Write purchased model number here.
Escriba aquí el número del modelo comprado.
Inscrivez le numéro de modèle ici.
You may need/Usted puede necesitar/Articles dont vous pouvez avoir besoin:
1/8" (3.17mm)
For easy installation of your Delta
faucet you will need:
• To READ ALL the instructions completely
before beginning.
• To READ ALL warnings, care, and maintenance
information.
• To complete the deck and valve rough-in prior to
installing this trim kit.
Para instalación fácil de su llave Delta
usted necesitará:
• LEER TODAS las instrucciones completamente
antes de empezar.
• LEER TODOS los avisos, cuidados, e
información de mantenimiento.
• Para completar el borde y la instalación de
válvulas dentro de las paredes previa a la
instalación de la llave y sus accesorios.
Pour installer votre robinet Delta
facilement, vous devez:
• LIRE TOUTES les instructions avant de débuter;
• LIRE TOUS les avertissements ainsi que toutes
les instructions de nettoyage et d'entretien;
• Installez le corps du robinet et terminez le
pourtour du bain avant de poser les accessories
de finition.
TWO HANDLE ROMAN TUB TRIM
61301
LLAVE Y SUS ACCESORIOS
PARA BAÑERA ROMANA DE DOS
MANIJAS (MANERALES)
ACCESSOIRES DE FINITION DE
ROBINET À DEUX POIGNÉES POUR
BAIN ROMAIN
3/32"
(2.38mm)
?
61301
1
3/32" (2.38mm)
1/8" (3.17mm)
1/15/10 Rev. B
Publicité
Manuels Connexes pour Delta Addison Serie
Sommaire des Matières pour Delta Addison Serie
- Page 1 (2.38mm) • To complete the deck and valve rough-in prior to installing this trim kit. Para instalación fácil de su llave Delta usted necesitará: • LEER TODAS las instrucciones completamente antes de empezar. • LEER TODOS los avisos, cuidados, e información de mantenimiento.
- Page 2 MAKE ANY OTHER WARRANTY OF ANY KIND, INCLUDING THE IMPLIED WARRANTY OF MERCHANTABILITY. Delta will replace, FREE OF CHARGE, during the warranty period, any part or finish that proves defective in material and/or workmanship under normal installation, use & service. Replacement This warranty excludes all industrial, commercial &...
- Page 3 Model / Modelo / Modèle T2792 RP61277▲ RP61280 ▲Specify Finish Finial 1 Red & 1 Blue Handle Button - Perilla Not included with model ▲ Especifíque el Acabado Bouton 1 rojo y 1 azul botón de la manija - ▲ Précisez le Fini no proporcionadas con el modelo 1 rouge et 1 bleue bouton de manette - non fournis avec le modèle...
- Page 4 T4792 RP40668 Diverter Assembly Ensamble del Desviador Dérivation Maintenance If faucet leaks from spout outlet–Shut off water supplies– Model T4792 Replace Seats and Springs (1). * If faucet does not divert water from the spout to the hand shower, check that If leak persists–Shut off water supplies–...
- Page 5 T2792 T2792 T4792 T4792 3/32" (2.38 mm) 3/32 po NOTE: The deck and valve rough-in must be finished before Place bases (1) with gaskets (2) over end valves (3) and secure installing the trim kit. with locknut (4). OPTION: Use silicone under the gasket if deck is uneven.
- Page 6 T4792 T4792 T4792 T4792 For Model T4792 Only Slide hose (1) through conical nut (2). Attach hose (1) to braided Install lift rod (1). Screw the lift rod until it drops down and metal hose (3) using gasket (4) and tighten. DO NOT install hand rotates freely.
- Page 7 T2792 T4792 Model T2792 Install handles. Be sure glide ring (1) is properly seated in Turn faucet handles (1) all the way on. Turn on hot and cold water supplies bottom of handle before installing. If either handle does not and flush water lines for one minute.
- Page 8 T4792 T4792 For Model T4792 Only Pull hose (1) to its farthest extension and point it down into the Attach hand piece (1) to hose (2) with gasket (3) between tub. Pull the lift rod (2) up to the full on position and flush water connection.
