WeatherTech TechLiner 88TG08 Instructions D'installation

Tailgate TechLiner
88TG08
1 1
Lower the tailgate and remove all tailgate accessories. Clean
your truck bed and tailgate with soap and water or TechCare
Gentle Car Shampoo. Dry thoroughly before installation. Note
™
the location of the hook and loop pads on the bottom of the
Tailgate TechLiner and keep them clean and clear of debris. Do
not remove the adhesive backing at this time.
3 3
Remove the three plastic extrusions from the parts bag. Starting
from one end, place the first extrusion against the edge of the
steel panel using the channel as shown. The remaining two
extrusions will be placed end to end, resulting in one extrusion
that runs the width of the tailgate. Tighten the 4 bolts that were
loosened previously.
5 5
Position plastic washers from the parts kit on the bolts so the
large diameter of the washer goes under the existing washer
as shown. Hand tighten all 4 bolts in their original holes first,
then tighten each one using the Torx bit. Start with the center
two bolts first, then the outer two. Do not over tighten.
®
Installation Instructions
Remove
2 2
Using a ¼" driver and enclosed Torx bit, remove the 4 bolts and
washers shown in Fig. 2. Loosen the 4 bolts shown in Fig. 2.
Do not discard bolts; you will use them in a later step.
4 4
Tuck the rear edge into the plastic extrusion that you just
installed. Next, align all of the contours of the Tailgate
TechLiner to the contours of your tailgate for a seamless fit.
6a 6a
Bend the Tailgate TechLiner backward to locate the hook and
loop pads without shifting its position. For standard painted
surfaces, use the supplied alcohol wipes to thoroughly clean
the areas that the hook and loop will occupy. Allow tailgate to
dry completely.
What You Need
¼" Driver*
Parts Kit #88TG08
(1) T-25 ¼" Insert Bit
(6) Plastic Shoulder Washers
(you will use only 4)
(3) Extrusions
(2) Primer 94
(2) Alcohol Wipes
*Not included
Loosen
