b) Assembling/changing the battery
The battery pack fits only one way. Do not force it into the battery compartment (5).
1. Slide the battery pack into the battery compartment until it "clicks" in place.
2. To remove the battery, push the locks on the side of the battery and pull it out.

8. Operation

a) Setting the rotation direction
1. To set the tighten rotation direction, press the tighten/loosen rotation control switch (2) through to the left stop
(Ú Fig. 3).
2. To set the loosen rotation direction, press the tighten/loosen rotation control switch (2) through to the right stop
(Ú Fig. 4).
Fig. 3
22
Fig. 4
