Portable Infra-Red Heater for Nonresidential Space Heating Owner’s Manual MODELS CHD24B AND TTC24B HEATER SIZE: 8,000 – 24,000 BTU/HR FOR YOUR SAFETY If you smell gas: 1. Shut off gas to appliance. 2. Extinguish any open flame. FOR YOUR SAFETY Do not store or use gasoline or other flammable vapors...
TABLE OF CONTENTS Safety Information ..........2 Maintenance ............5 Assembly ............. 3 Replacement Parts ..........5 Connecting Heater To Propane Tank ....3 Parts List ............. 6 Lighting Heater ............ 4 Heater Information ..........6 To Turn Off Heater ..........5 Warranty Information ...........
ASSEMBLY 1. Place each burner head onto the burner bracket as shown in Figure 1. CAUTION: The burner heads should be positioned as far down on the burner bracket as possible. Make sure the air inlet holes in the mixing tube on the burner head are not covered by the burner bracket.
LIGHTING HEATER Read and understand all safety information before operating heater. 1. Adjust burners to desired position by loos- ening wing nuts on back of burner head bracket. WARNING: Wing nuts and burner heads become very hot during operation. Do not attempt to adjust burner position while heater is operating.
DESA Industries at 1-905-826-8010. propane supply, operating, or When calling DESA Industries, have ready: hot. Severe burns can occur. • your name and address • Keep heater clear and free •...
PARTS LIST Item Description Part Number Burner Guard 100911-01 Thermocouple 100886-01 Regulator with Fuel Gas Connector LPA 2025 Warning Plate (not shown) 101834-02 Burner Replacement Kit* (not shown) LPA5050 * Replace burner screens that are worn, split or broken. HEATER INFORMATION Btu Input One Burner Two Burners...
Propane Infra-Red Tank Top Heater Limited Warranty DESA Industries warrants this product and any parts thereof, to be free from defects in materials and workmanship for one (1) year from the date of first purchase when operated and maintained in accordance with instructions. This warranty is extended only to the original retail purchaser, when proof of purchase is provided.
Chauffage à infra-rouge portable pour chauffer les espaces non residentiels MODÉLES CHD24B ET TTC24B PUISSANCE : 2,34 À 7,03 KWH (8 000 À 24 000 BTU/HR) POUR VOTRE SÉCURITÉ Si vous sentez le gaz : 1. Coupez le gaz vers l’appareil.
TABLE DES MATIÉRES Informations sur la sécurité ......... 2 Entretien .............. 5 Montage .............. 3 Pièces détachées ..........5 Branchement de l’appareil de chauffage à une Liste des pièces ........... 6 bouteille de propane ..........3 Renseignements sur l’appareil de chauffage ..6 Allumage de l’appareil de chauffage ....
MONTAGE 1. Placer chaque tête de brûleur sur le support de celui-ci comme indiqué à la figure 1. ATTENTION: Veiller à placer les têtes de brûleur aussi bas que possible sur le support du brûleur. Veiller à ne pas couvrir les trous d’entrée d’air du tube de mélange, situés sur le couvercle du brûleur, avec le support de tête de brûleur.
ALLUMAGE DE L’APPAREIL DE CHAUFFAGE Avant de faire fonctionner lʼappareil de chauffage, lire attentivement et veiller à bien comprendre toutes les informations concernant la sécurité. 1. Desserrer les écrous à oreilles, à lʼarrière du support de tête de brûleur, pour placer les brûleurs à...
1. Maintenir lʼappareil propre. Le nettoyer an- de DESA Industries au 1-905-826-8010, et être nuellement ou selon le besoin pour le débarras- prêt à fournir : ser de la poussière et des débris.
LISTE DES PIÈCES Article Description Numéro de pièce Protection de brûleur 100911-01 Thermocouple 100886-01 Détendeur avec connecteur pour gaz combustible LPA 2025 Plaque de mise en garde (non représentée) 101834-02 Kit de remplacement de brûleur (non représentée) LPA5050 *Remplace les écrans de brûleur usés, fendus ou cassés. RENSEIGNEMENTS SUR L’APPAREIL DE CHAUFFAGE Un brûleur Les deux brûleurs...
Appareil de chauffage infrarouge sur bouteille garantie limitée DESA Industries garantit que ce produit et ses pièces sont exempts de vices de matériaux et de fabrication, pendant une (1) année à compter de la date dʼachat initial, lorsque ledit produit est utilisé et entretenu conformément aux instructions.
