R/W
R/W
Der Registerwert kann durch den Befehl ATSn=m<cr> aktualisiert und mit dem Befehl ATSn?<cr> angezeigt
werden.
Die Register werden in 2 Typen unterteilt: nur lesen (R) oder lesen/schreiben (R/W)
7.

Spezifikationen

Supply voltage
Transmission consumption
Reception consumption
Operating temperature
Packaging
Size / Weight
Standard compliance
Programmable frequencies
Frequency stability
Channel Spacing
Air rate
Modulation
Output power
Output impedance
Sensitivity
Adjacent channel rejection
Intermodulation
Serial data rate
Serial ports
Setupandconfiguration
Modes
UG_ARF73 V1.7
All manuals and user guides at all-guides.com
S237 Owner
S260 Firmware
upgrade

Allgemeine technische Eigenschaften

10 to 28 Volts
16VA (under 4W)
2VA
-30°C to +70 °C
IP65 Box with TNC female antenna
connector
169x100x55 mm + antenna / 710g
EN300-113 / EN301-489 / EN60950
Hochfrequenz
406 to 470MHz (under licence)
± 1kHz
12.5kHz
4800 bits/s
9600 bits/s
Transmitter
GMSK BT=0.5
0.5W (27dBm)
1W (30dBm)
2W (33dBm)
4W (36dBm)
50 Ohms
Empfangsgerät
-112 dBm
65dB typ.
65dB
Protokoll
4800bps
9600bps
19200bps
38400bps
57600bps
115200bps
RS232 port -> ref ARF7499B
RS485 port -> ref ARF7499C
through Hayes commands
Transparent/Addressed/Repeater mode
An available register with
free format for customer
information
Must always be left to 0
0 -> no upgrade
1->upgradefirmwareafter
next ATO command
Software selectable
Software selectable
Software selectable
blank
0
