Skid Loader Framesheet
RETAILER: This framesheet MUST BE provided to the end user.
Thanks for spending your hard-earned money on a Surly Skid Loader. Seriously, we really appreciate it. You could've picked something else
but you didn't, and that means a lot to us. We've put a lot of work into making a great-riding bike that you'll enjoy for a long time. Before you
read any further take a minute and write down this frame's serial number. If you should ever experience a problem with it, the serial number
will help us get things sorted, and if your bike is ever stolen the serial number is undeniable proof that it's yours. So take a minute and write
it down. Your frame's individual serial number is located on the top of the motor mount.
SERIAL NUMBER:______________________________
WARNING: Cycling can be dangerous. Bicycle products should be installed and serviced by a professional mechanic.
Never modify your bicycle or accessories. Read and follow all product instructions and warnings including information
on the manufacturer's website. Inspect your bicycle before every ride. Always wear a helmet.
For additional product and safety information, Surly owner's manuals, or Bosch component manuals, please visit surlybikes.com/safety.
Please note that the specifications and information in this particular framesheet are subject to change for product improvement. For the latest
information, go to surlybikes.com or Bosch-ebike.com.
Frame Compatibility
Tubing: 100% Surly Chromoly steel, Natch tubing, double-butted main triangle, TIG welded
Rear hub compatibility: 12 x 148mm
Brake compatibility: 74mm Post; 203mm max rotor size
Water bottle mounts: One to two (depends on frame size and battery configuration)
Fender mounts: Yes (compatible only with quick-release fenders)
Rack mounts: Yes (M6 bosses for dedicated rear rack)
Other accessory compatibility: Kickstand plate; internal cable routing for dropper post, brake, derailleur and light;
Dual Bosch PowerPack Battery Mounts
Seatpost: 30.9mm
Seatpost clamp: 33.1mm
Headset/Steerer tube: EC34/28.6 upper, EC34/30 lower
Tire clearance: 27.5 x 2.8". Note: Individual tire and rim combos effect tire clearance
Intended Use
CONDITION 2
This is a set of conditions for the operation of a bicycle that includes Condition 1 as well as unpaved and gravel roads
and trails with moderate grades. In this set of conditions, contact with irregular terrain and loss of tire contact with
the ground may occur. Drops are intended to be limited to 15cm (6") or less. Please see link to Bike Owner's Manual on
surlybikes.com/safety for complete list of riding condition descriptions.
WARNING:
• Do not use forks exceeding your frame's maximum axle-to-crown dimensions; see www.surlybikes.com and the product page for
posted maximum axle-to-crown requirements. Exceeding the maximum axle-to-crown will void the frame warranty and may result
in damage to or failure of the frame, causing serious injury.
• Always check for 6mm of clearance between the tire and frame, fork, or any accessories.
• Failure of a front rack or entanglement of cargo or straps in either wheel could stop the rotation of the wheel, causing a loss of
control or crash that could lead to serious injury. If you have a front rack mounted to your frame, check the security of all mounting
hardware and fasteners before every ride, and retighten to manufacturer specifications if necessary. Never exceed the load limits
of a front rack or carry passengers. Make sure your cargo and straps do not interfere with the function of your bicycle before
attempting to ride. Ensure even cargo distribution, and confirm lights and reflectors are not obstructed.
Note: this frame is compatible only with quick-release fenders. Do not use this frame with fenders that lack a quick-release feature that will
release the fender in case an object becomes lodged in your wheel or spokes.
AB 1096 CALIFORNIA E-BIKE CLASS: CLASS 1, MOTOR: 250W, SPEED LIMIT: 20 MPH
WARNING: Your e-bike is intended for use by persons 16 years of age and older. Riders must have the physical coordination,
reaction, and mental capabilities to control a bike and manage traffic, road conditions, and sudden situations, and also to respect the
laws and instructions governing bicycle use.
MAXIMUM WEIGHT LIMIT
Rider: 300 lb (136kg)
Cargo: 100 lb (90kg)
Max Combined: 400 lb (181kg)
6400 West 105th Street, Bloomington, MN 55438
P 877.743.3191 E derby@surlybikes.com W surlybikes.com
449850 4/22 | 85-001451_INST_A
