# Qty. Description
1 1
Fan Housing
2 4
Mounting Rails
3 1
External Wire Cover
4 1
Screw
5 3
Screw
6 1
Gasket - Collar
7 1
Metal Collar
8 2
Damper
9 2
Bushing
10 1
Rod
11 1
Spring
12 1
Light Harness
13 1
Internal Wire Cover
14 1
Screw
15 1
Motor Cap Harness - AKF50LS
1
Motor Cap Harness - AKF80LS
1
Motor Cap Harness - AKF100LS
16 1
Screw
17 7
Blower Screws
18 1
Motor Plate
19 1
Venturi
210572203 Rev. C 3-10
All manuals and user guides at all-guides.com

REPLACEMENT PARTS DIAGRAM

Replacement Part #
5S1202033
5S1299002
5S1202007
5S1999010
5S1999010
5S1202029
5S5202002
5S5202006
5S5202003
5S5202005
5S5202004
5S1202088
5S1202089
5S1999010
5S2202031
5S2202007
5S2202012
5S1999009
5S2202004
5S2202005
5S2202006
www.airkinglimited.com
# Qty. Description
20 1
Reflector Support Bracket
21 1
Blower Wheel
22 2
Screw
23 1
Motor
24 5
Screw
25 1
26 Watt Lamp Holder
26 1
Light Reflector
27 1
Bushing
28 1
Clip
29 1
Ballast Mounting Bracket
30 2
Screw
31 1
Glass Lens
32 1
Grill
33 4
Lens Clips
34 2
Grill Springs
35 1
Reflector/Ballast/Ground
36 1
26 Watt Ballast Harness
37 1
Outlet Gasket
38 1
#10 Ground Screw
39 1
14 ga Ground Wire
Replacement Part #
5S1202036
5S2202003
5S2202002
5S2202001
5S1202037
5S1202090
5S1202015
5S1202018
5S1202017
5S1202091
5S1202040
5S5202001
5S1202020
5S1202021
5S1202092
5S1202093
5S1202042
5S1202043
5S1999002
5S1999003
5 of 12
