13. Documentation for routing diagram

The routing diagram is shown in section 16.2.

13.1 In general

When configuring the 9203, you will be guided through all parameters
and you can choose the settings which fit the application. For each
menu there is a scrolling help text which is automatically shown in line
3 on the display.
Configuration is carried out by use of the 3 function keys:
will increase the numerical value or choose the next parameter
will decrease the numerical value or choose the previous parameter
will accept the chosen value and proceed to the next menu
When configuration is completed, the display will return to the default
state 1.0.
Pressing and holding
default state (1.0) without saving the changed values or parameters.
If no key is activated for 1 minute, the display will return to the default
state (1.0) without saving the changed values or parameters.

13.2 Further explanations

13.2.1 Password protection

13.4 Advanced functions

The unit gives access to a number of advanced functions which can be
reached by answering "Yes" to the point "adv.set".
6
9203 Solenoid / Alarm Driver
will return to the previous menu or return to the
Access to the configuration can be blocked by assigning a
password. The password is saved in the device in order to
ensure a high degree of protection against unauthorised
modifications to the configuration. Default password 2008
allows access to all configuration menus.
Password protection is mandatory in SIL applications.
Version No. V5R0
