OVERVIEW
1. Platter
Place your record here.
2. Arm Clip
This specially designed arm clip secures the tonearm while at
rest or when not in use.
3. Autostop Switch ON/OFF
This switch turns auto stop on or off. When the automatic stop
is enabled, the platform will start rotating as soon as the tone
arm is placed over the record and will stop rotating when it has
reached the end of the record. Some vinyl records stop before
the end or do not stop when the end is reached. In this case
set Auto-stop to OFF.
4. 33 / 45 / 78 RPM Switch
This switch controls the RPM of the turntable platter.
5. Tone arm
The fixed tonearm can be raised and lowered by hand, or by
pressing the raise / lower lever.
6. Power & volume control knob
To power on the record player, turn this knob clockwise until it
clicks. When powered on, use this knob to adjust the volume
for the internal speakers and headphones. To turn off the record player, turn this knob counter clockwise until it clicks.
7. Line input
Connect a CD player, digital media player, or other audio source to this 3,5mm (1/8") stereo line input.
8. USB port
Use the included USB cable to connect your turntable to your computer. The USB connection will send audio from the
turntable to your computer
9. DC IN port
Connecting the 12Volt/DC power adaptor.
10. Line output
The audio from a playing vinyl record is sent to this line-level coaxial audio output. This must not be connected to
phono level devices.
OPERATION
1. Open the top lip. Move the lock door following the direction from picture.
Note: There is no key for lock. It is decoration only for the key hole.
2. Connect the record player with the power adapter and plug the other end into a wall power outlet.
3. Remove white protective needle cover by gently pulling towards the front of the unit.
4. Place a vinyl record on the turntable platter and select the desired speed (33/45/78 RPM)
according to the record.
5. Open the tone arm clip to release the tone arm. Gently move the tone arm and put the cartridge
onto the desired position of the record and the turntable player starts to play.
6. Turn the volume control knob clockwise to adjust the volume.
Noted: If the AUTO STOP ON/OFF Switch is turned ON, the record will stop automatically when finished If Auto Stop Control is
turned OFF, record will NOT stop automatically when finished.
