Appendix (English); Technical Specifications - ION Garage Rocker Mode D'emploi

Appendix (English)

Technical Specifications

Output Power
Drivers
Frequency Response
Bluetooth Specifications
Microphone Type
Radio Frequency Range
USB Charging Port
Mechanical Features
Water Resistance Class
Battery
Power
Dimensions
(width x depth x height)
Weight
Specifications are subject to change without notice. Bluetooth and wireless reception and range are
affected by walls, obstructions, and movement. For optimal performance, place the product in the center of
the room so it is unobstructed by walls, furniture, etc. Battery life may vary based on temperature, age, and
volume usage of product.
Trademarks & Licenses
ION Audio is a trademark of ION Audio, LLC, registered in the U.S. and other countries. Facebook is a
trademark of Facebook, Inc. The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and
any use of such marks by ION Audio is under license. The N Mark is a trademark or registered trademark of
NFC Forum, Inc. in the United States and in other countries. All other product names, company names,
trademarks, or trade names are those of their respective owners.
38
50 W (peak)
Low-Frequency: 6.5" / 165 mm woofer
High-Frequency: 2.0" / 50 mm tweeter
65 Hz – 20 kHz (±3dB)
Profile: A2DP, AVRCP
Range: Up to 100 feet / 30.5 meters
Dynamic microphone recommended (not included)
US: 520–1710 kHz (AM), 87.5–107.9 MHz (FM)
Europe: 522–1629 kHz (AM), 87.5–108 MHz (FM)
Japan: 522–1710 kHz (AM), 75.5–108 MHz (FM)
1 USB, +5 V, 1 A
Top Panel: rulers for imperial and metric units, protractor, magnetic tray
for screws/parts, drill bit size identifier, drill bit holder, socket tray.
Side Panel: Magnetic strip for holding tools
IPX5 - protection from a 6.3 mm spray of water (12.5 liters per minute) for
3 minutes, and dust protection to not interfere with normal operation.
Battery life: Up to 50 hours
Recharge time: 10 hours
Type: 12 V, 5.0 Ah, SLA
Dimensions: 2.8" x 3.5" x 4.0" / 71 x 89 x 102
Connection: IEC
Input Voltage: 100–240 VAC, 50/60 Hz
16.1" x 9.6" x 13.7"
410 x 244 x 348 mm
17.9 lbs.
8.1 kg
