- GB -
Pos: 94 /Alle Produkte/Überschriften/H1 Inbetriebnahme @ 7\mod_1196625111244_121.doc @ 41417
5. Start-up
Pos: 95 /Filter/SwimSkim CWS/INB Inbetriebnahme SwimSkim CWS @ 8\mod_1221649414453_121.doc @ 52913
Attention! Dangerous electrical voltage.
Possible consequences: Death or severe injury.
Protective measures: Disconnect the power plug (Figure E, 15) prior to reaching into the water and
commencing work.
Follow the safety information!
The pump in the SwimSkim CWS switches on automatically when the power connection is established.
Switching on (Fig. E): Plug the power plug (15) into the socket.
Switching off (Fig. E): Disconnect the power plug (15).
The pump is equipped with a dry run protection. If no water is primed, the pump switches off ten times
for approx. 3 seconds each. Following this the pump shuts down.
Switching on the pump again:
Pull the power plug (15) and reinsert into the socket (reset function).
►
Pos: 96 /Alle Produkte/Dummy_module/Abstand 18 pt @ 6\mod_1196355593257_0.doc @ 41089
Pos: 97 /Alle Produkte/Überschriften/H1 Reinigung und Wartung @ 7\mod_1196625212761_121.doc @ 41469
6.

Maintenance and cleaning

Pos: 98 /Filter/SwimSkim CWS/WAR Reinigung und Wartung SwimSkim CWS @ 8\mod_1221649546672_121.doc @ 52939
Attention! Dangerous electrical voltage.
Possible consequences: Death or severe injury.
Protective measures: Disconnect the power plugs of all the units in the water prior to reaching into the
water and commencing work.
Regular cleaning (Figure F)
1. Remove the filter basket (8).
You can leave the SwimSkim CWS in the water by hooking in a sufficiently long pole at the
−
handle (4) and removing the filter basket (8).
2. Clean the filter basket (8) with clean water and a soft brush. If a foam filter (7) was used before,
clean same additionally with clean water.
3. Set the filter basket (8) in the SwimSkim CWS again.
Complete cleaning (Figure F-I)
1. Remove the unit from the water.
2. Remove filter basket (8) and, if necessary, the foam filter (7).
3. Undo three screws (17) from the container and remove the container (16).
4. Disconnect the air hose (24) connected to the intake socket (23) from the air controller (25). During
cleaning, the air hose (24) remains in the intake socket (23).
5. Unscrew the flow-out nozzle (3).
6. Remove the pump (18) from the pump chamber (1)
7. Disassemble the pump (18):
Pull off the intake socket (23).
−
Unscrew four screws (19) from the rear of the pump.
−
Remove pump housing (22), O-ring (21) and the impeller (20).
−
8. Clean all components using clean water and a soft brush. If a foam filter (7) was used, clean same
with clean water.
9. Reassemble the unit in the reverse order.
Pos: 99 /Alle Produkte/Dummy_module/===== Seitenwechsel ===== @ 0\mod_1125648978015_0.doc @ 1630
12
