VITRA AutoClean Metropole Mode D'emploi page 6

AutoClean Washbasin, Conditions of Use
AutoClean Washbasin washing system has been designed to eliminate residues and dirt
which may be formed in the washbasin over time. The system cleans the washbasin by
mixing water and detergent and makes it cleaner and hygienic. The system comes in two
EN
models, one activated by button and the other by sensor.
1- Points to Consider when Using Washbasin Sensor System
Conditions of Use
2sn
for 1 second. The sensor takes maximum 2 sec to stop. Moreover, when the sensor is
activated once and does washing, the hand/object needs to get out of the detection range
and re-enter it for a 2 washing.
Distances of approach to the sensor are as follows.
- Functions in a range of 1-7 cm.
- 5 cm (factory preset)
2- Points to Consider when Using Washbasin Push Button
Conditions of Use
Points to Consider when Using Auto Clean Washbasin
1. It is a system which distributes detergents and perfuming substances put in the liquid
detergent reservoir to the bowl after the use.
2. The system may not be enough by itself to remove sticky and persistent stains such as
tooth brush and shaving foam. Such residues may be cleaned with a cloth or brush.
3. The liquid detergent dispenser has been designed to distribute a mixture of water and
some of the detergents in the reservoir into the bowl upon the activation of the
washbasin cleaning system.
4. Never put abrasive liquids and detergents such as hypochlorite, bleacher, drain opener,
toilet detergent, hydrochloric acid in the liquid detergent reservoir. You may add
non-abrasive detergents, perfuming additives and detergents which do not contain
particles.
5. It is advisable to use one single type of detergent. You should certainly avoid mixing
different detergents in the detergent reservoir.
6. Once filled fully, the liquid detergent reservoir can make up to 300-400 washing.
7. It is important not to put detergents which have a thick texture, contain particles and may
form foam in the liquid detergent reservoir. Foaming can have a negative effect on
washbasin functioning.
Normal Use: When the user moves a hand close to the sensor, the
system is activated and does a washing inside the washbasin. The
washing lasts 4-5 seconds, using 1 lt water and mixing 3-6 ml detergent
with water to wash the basin. When the detergent in the reservoir runs
out, the system cannot do the washing fully.
- Detection Distance: The system comes, factory preset, with a detection
range of 5 cm. The sensor functions when the hand is held still
nd
Normal Use: When the user pushes the button with hand, the system is
activated and does a washing inside the washbasin. The washing lasts
4-5 seconds, using about 1 lt water and mixing 3-6 ml detergent with
water to wash the basin. When the detergent in the reservoir runs out,
the system cannot do the washing fully.
5
