2.1 Packing Details.

Each unit of Tablet PC has the following items: Tablet PC device*1, charger*1, earphone*1, USB
cable*1, and user manual*1. All items are packed in gift box.

2.2 Instructions on Keys.

Name
POWER
MENU
ESC
TF Card Slot
Stereo Earpieces Jack
DC Socket
MINI USB Port
USB Host Port
Display
Long Press: Press the item for more than 1.2 seconds.

2.3 Features Overview

 CPU: ALLWINNER, Cortext A8, 1.2GHz. With ANDROID 2.3 operation system.
 7" TFT touch panel LCD display, 800 x 480 pixel resolution.
 Support 4~16GB built-in Flash Memory, support 128MB-16GB external TF card.
 Support Media playing: Video, audio, pictures, Ebooks, etc.
 Built-in Wi-Fi. Support external 3G USB-DONGLE wireless network card (3G card or
USB-Dongle are not provided by the Tablet PC manufacturer).
 Various applications are available in the ANDROID 2.3 OS (APK applications only).
 Support built-in microphone record function (optional).
 Support USB-HOST and external U-disk, MP3, MP4, Mouse, keyboard, etc.
 Support G-sensor screen rotation function.
 Support Stereo Earpieces and speaker.
 Supports multiple languages.
 The device can be used as USB portable hard disk, driver not needed for WIN2000 or above.

2. Introduction

Press this button shortly to enter sleeping/wake up mode, long
press to switch ON/OFF
Press this button shortly to enter the submenu
Press shortly to return, long press to the touch screen
calibration
For external TF card, 1GB to 16GB
Stereo earpieces jack for earphone
Connect with 5V DC charger
MINI_5 PIN USB Port
Port for external USB Driver, 3G Dongle, Mouse, keyboard,
etc
HD Display area
Description
