Monitors
Models EC5603-M and EC7003-M
WARNING!
To prevent accidental shock, DO NOT OPEN THE MONITOR CASE. Opening the monitor case will expose the inside of the monitor to
conditions that could adversely affect performance. Any evidence of tampering with sealed components will void the warranty.
Important! Do not expose the monitor to water, it is not waterproof. Any water that leaks into the monitor could cause extensive damage.
Installation: EC5603-M/EC7003-M
Installation instruction of using U-support bracket
1. Select suitable position on vehicle and fix the U-support bracket with screws (Figure 3)
2. Fix the monitor to the U-support bracket with angle adjustment screws and adjust the view angle of the monitor
3. Put on the sun-visor and connect the monitor with the AV and power supply conversion cable (Figure 4)
Figure 3
Figure 4
Page 5 of 10
