Getting to know your CU4K30
Front view
1. Headset port
2. LED indicator
3. Game pad port
LED indications
Status LED Indicator
Static green
Static blue
Color cycle effect
Working Rainbow effect
Static red
Flashing red
Flashing yellow
Breathing orange
Firmware
Static orange
upgrading
Flashing red
Rear view
4. USB 3.2 Gen1x1 Type-C®
5. HDMI IN port
6. HDMI OUT port
Indications
Standby mode (USB 2.0)
Standby mode (USB 3.2 Gen1x1)
Working mode (Party mode on)
Working mode (Party mode off )
HDCP/Upscaling or downscaling failure
Device/USB abnormal
HDMI input interrupted
Firmware upgrading
Firmware upgraded successfully
Firmware upgrade failed
3
